Reducer applicable scope is as follows:
1, high speed rotation is not more than 1500 r/min.
2, gear circumferential velocity is not more than 20 m/s.
3, working environment temperature for - 40-45 ℃, if lower than 0 ℃, before the start of lubricating oil should be preheated to 0 ℃ above, the speed reducer can be used in positive and negative two directions.
The characteristics
1. Gear is made of high strength low carbon alloy steel after carburizing and quenching, tooth surface hardness is HRC58-62, gear adopts CNC gear grinding technology, high precision, good contact.
2. High transmission rate, single stage is greater than 96.5%, double level greater than 93%, level 3 is greater than 90%.
3. Smooth operation, low noise.
4. Small size, light weight, long service life, high bearing capacity.
5. Easy to overhaul, easy to install
Specification
1. Types are: ZDY single stage spur gear reducer, ZLY two-stage cylindrical gear reducer, ZSY cylindrical gear reducer, ZFY four cylindrical gear reducer.
2. Specification: single stage: 80, 100, 125, 160, 125, 250, 280, 315, 280, 315, 450, 500, 450;
Two levels: 112, 125, 140, 160, 180, 200, 180, 250, 280, 315, 355, 400, 355, 400, 560, 630, 560;Level 3:160, 180, 200, 180, 250, 280, 315, 355, 400, 450, 500, 560, 500, 560;Level 4-180, 200, 225, 250, 225, 320, 360, 400, 360, 360, 560, 630, 710, 630.
