Spiral tube former machine
- 0 per Month
- shanghai
- T/T
- CNC router for stone processing engraving machine
- Glass polishing machine JMB95A
- Aluminum Profile Bending Machine/Arc Bending Machine for Aluminum
- Automatic aluminum window corner connector cutting machine
- aluminum door and window frame cutting machine aluminum windows and doors machine
- Upvc Window Door Machine Four Head Welding Machine for PVC welding Window Machine
Product Details
Type: | Pipe Molding Machine | Pipe Material: | Stainless Steel | Place of Origin: | Jiangsu, China |
Brand Name: | hongjun |
Product Description
Specifications
Spiral Tube former machine1.Diameter range80-1600mm2.Thickness of strip0.4-1.3mm Glvanized steel0.8mm Sinless steel0.4-1.2mm
Spiral Tube former machine
Main Technical Specification:
Diameter range | 80 – 1600mm |
Thickness of strip | 0.4 -1.3mm Glvanized steel |
0.8mm Sinless steel | |
0.4-1.2mm Auminum | |
| |
Strip Width | standard 137mm up to 1mm thickness, 140mm above. Other widths on request. |
Lock seam | Outside tube, on the inside on request. |
Production speed | Max. 60 meters/min. depending on material |
Cutting system | The pqtented flying slitter |
Net weight | 2900kg |
Gross weight | 3200kg |
Machine dimension | 3000mm*1950mm*1700mm, |
Package dimension | 3050mm*2000mm*1800mm |
Options | Automatic length control system, controlled corrugation unit.METU flange slitter Saw blade cutter |
The module technique gives the customer the possibility to choose between a number of options, allowing him to create a machine a number of options, allowing him to create a machine for his specific needs.
The frequency controlled main drive ensures a smooth acceleration and an almost noiseless operation.
The outstanding patented flying slitter cuts the tubes to length without noise or hot sparks as known from the saws and provides smooth tube ends without deburring.
The design and options fulfill the needs in HVAC to produce in mild steel, galvanized steel, stainless steel or aluminum
The corrugation unit allows a reduction in material costs and makes the bigger diameter tubes more rigid.
