12V 30A 350W Power supply CE ROHS
DC12V 24V power supply is our best selling products, which is with single output . EU,US plug is available for us .
Wholesale single output DC12v 24v 30a 350W model dc power supply with US EU Plug for rc battery is suitable for all kinds of electrical products ,
Specification :
| Model Specification | S-350-5 | S-350-7.5 | S-350-12 | S-350-15 | S-350-24 | S-350-27 | S-350-48 |
| DC output voltage | 5V | 7.5V | 12V | 15V | 24V | 27V | 48V |
| Output voltage error | ±2% | ±2% | ±1% | ±1% | ±1% | ±1% | ±1% |
| Rated output current | 50A | 40A | 29A | 23.2A | 14.6A | 13A | 7.3A |
| Output current range | 0-50A | 0-40A | 0-29A | 0-23.2A | 0-14.6A | 0-13A | 0-7.3A |
| Wave and noise | 50mVp-p | 150mVp-p | 150mV | 150mV | 150mV | 200mV | 240mV |
| Inlet stability | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
| Load stability | ±1% | ±1% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
| DC output power | 250W | 300W | 348W | 348W | 350.4W | 351W | 350.4W |
| Efficiency | 78% | 79% | 83% | 83% | 84% | 85% | 86% |
| Adjustable range for DC voltage | 4.5-5.6V | 6-9V | 10-13.2V | 13.5-18V | 20-26.4V | 26-32V | 41-56V |
| AC input voltage range | 90~132VAC/180~264VAC BY SWITCH 47~63Hz;248~370VDC | ||||||
| Input current | 6.5A/115V 4A/230V | ||||||
| AC impulse current | 25A/115V 50A/230V | ||||||
| Leakage current | <3.5mA/240VAC | ||||||
| Overload protection | 105%~135%. Type,PULSING HICCUP SHUTDOWN; Reset,auto recovery | ||||||
| Over-voltage protection | 5.75-6.75V | 9.4-10.9V | 13.8-16.2V | 18-21V | 27.6-32V | 33.7-39V | 57.6-67.2V |
| High-temperature protection | RTH3>=65°C FAN ON<=55°C FAN OFF>=80°CCut off output(5~15V) | ||||||
| RTH3>=70°C FAN ON<=60°C FAN OFF>=85°CCut off output(24~48V) | |||||||
| Temperature coefficient | ±0.03%°C(0~50°C) | ||||||
| Setup rise hold up time | 200ms,50ms,20ms | ||||||
| Vibration | 10~500Hz,2G 10min./1cycle,Period for 60min,EACH AXES | ||||||
| Withstand voltage | Input and output interval,1.5KVAC,Input and enclosure,1.5KVAC,Output and enclosure,0.5KVAC | ||||||
| Isolation resistance | Input and output interval,Input and enclosure,Output and enclosure,500VAC/100M Ohms | ||||||
| Working temperature and humidity | -10°C~+50°C,20~90%RH | ||||||
| Store temperature and humidity | -20°C~+85°C,10~95%RH | ||||||
| Overall dimension | 215*115*50mm | ||||||
| Weight | 0.95Kgs /17pcs per carton | ||||||
| Safety standards | Design refer to UL1012, EN60950-1,EN61347-1,EN-61347-2 approved | ||||||
| EMC standards | EN55015,EN55022,EN55024,EN61000-2,EN61000-3,EN61547 approved | ||||||
| Note,1.The testing condition for the parameter above is,230VAC input, rated load,25°C 70%Rh,Humidity | |||||||
| 2.Error,include the setting error, line stability and load stability.(Note,5) | |||||||
| 3.Wave test,adopting“A12”double wire for 20MHz,and 0.1uF&uF capacitor short-circuit for interrupting | |||||||
| 4.Inlet voltage stability test, when is over load, the lowest voltage of inlet is representative to the highest voltage. | |||||||
| 5.Load stability test: The load is from 0% to 100%,others 60%. | |||||||
| 6.C2,3,11must be knocked down | |||||||
Feature:
Switch power supply, convert AC 115V/230V to DC 12V .
Dual input voltage: AC 115V/230V. There is a switch, choose the proper voltage before use.
Steady and precise output voltage.
Shortage protection, overload protection(105%~200%), over voltage protection(115%~135%).
Widely used as the power adapter for Led strip, LED display, billboard, industrial equipment, etc. IN-DOOR USE ONLY!
Picture :
Q1: Can I have some samples for testing quality?
A1: Yes, you can buy some samples of any our products for testing quality and market.
Q2: How should I pay?
A2: You can pay via T/T,L/C at sight, PayPal, Western Union, Cash etc., 100% T/T in advance for samples. For large quantities, 30% T/T in advance as soon as order confirmed and the balance before shipping via T/T or L/C etc. If you prefer other payment terms, please contact us freely.
Q3: What is your package looks like? Can I have the customized package?
A3: We have factory's current standard package, customized print logo shall be complied to buyer's requirements, and the extra charges will be borne by the buyers, for more details, please contact us.
Q4: What is delivery time if we place an order?
A4: It depends order quantities. Usually, we can deliver goods within 3 -5 working days for small orders, for more QTY. order, let's confirm when you place offical order.
