Specifications
A.Founded in1980B.CE,ROHS,SGS,UL,KEMA,VDE,TSE,CB
C.ISO9001,14001
D.manufacturer
E. 430 employees,15000 square meter factory
Type:HL-5050, HL-5030, HL-5300, HL-5200, HL-5100, HL-5000
(limit switches HL,XCK,WL,D4D,AZ,ME,TZ,MEA,LK3,LDE3,KH
Limiting switches are ideal electrical control switches in mechanical and other industries.They have features of complete specifications and varieties of types. compact structure, nice appearance, excellent performance, flexible and reliabe action, easy installation, operation, maintenance and adjustment.
Protection degree | IP67 | |
life | Mechanical | ≥10.000,000times |
electrical | Electric life curve | |
Operation speed | 5mm-0.5m/s | |
Operation frequency | Mechanical | 120times/min |
electrical | 30times/min | |
Insulation resistance | 100mΩ DC 500V | |
Contact resistance | ≤25Mω(initial value) | |
Withstand voltage(50/60Hz/min) | Between the terminals of same pole | AC 1,000V |
Charged metal parts | AC 1,500V | |
Between non-charged metal parts of each terminal | AC 1,500V | |
Vibration | Mis-operation | 10-55Hz(amplitude)1.5mm |
load | AC 250V 5A |
AC 380V 5A | |
DC 125V 3A | |
AC 250V 3A |
| HL-5000 | HL-5030 | HL-5050 | HL-5100 | HL-5200 | HL-5300 | HL-5500 |
OF(max) | 750g | 750g | 750g | 900g | 900g | 150g | 2000g |
RF(min) | 100g | 100g | 100g | 150g | 150g |
| 200g |
PT(max) | 20° | 20° | 20° | 1.5mm° | 1.5mm° | 3mm | 1.5mm |
OT(min) | 50° | 50° | 50° | 4mm° | 4mm° |
| 4.5mm |
MD(max) |
|
|
| 30±0.8mm | 30±0.8mm |
|
|
....
