Specifications
A.Founded in1980B.CE,ROHS,SGS,UL,KEMA,VDE,TSE,CB
C.ISO9001,14001
D.manufacturer
E. 430 employees,15000 square meter factory
LZZJB9-10 type indoor medium voltage current transformer is a range of well cast-resin metering and protection combined current transformer, used in 50Hz, rated voltage up to 10kV and below AC power system. The way of wiring can be changed under request of customer.
TYPE DESIGNATION
LZZBJ9-10A
SPECIFICAIONS
Um 12kV
Test voltages 42/75kV
Rated primary current 10-1250A
Rated secondary current 5/1A
Rated dynamic current 2.5 x Ith
Rated frequency 50/60Hz
Accuracy 0.5,0.2/ 5P,10P
Rated accuracy limit factor FS<10
The current transformers are in accordane with GB1208 and IEC185 standards.
Rated insulation level 12/42/75/kV
Rated frequency 50Hz or 60Hz
Raed secondary current 5A or 1A.
Ambient temperature -45-+45
Pollution class IV
We can make high precision current transformers of 0.2S or 0.5S for measuring.
Using tap of secondary winding to have different current ratio
Using imported outdoor epoxy resin for casting.
2. Packing show
3. Company show
4. Production series
....
