DIXSEN Brand Low Voltage High Accuracy Mini Current Transformer

Specifications

1,CE, ROHS approval
2,Found in 1992
3,Professional manufacturer
4,ISO9001,ISO14001
5,Export to Europ, America, Asia, Africa



·DESCRIPTION
A old range of (5 frames) plastic case current transformer, quick connection terminals, low cost.

·FEATURE
Two built in fixing methods:DIN rail; Busbar mounting
Quick connection terminal Low cost
Primary current from 5A to 500A.

·SPECIFICAIONS
Rated Frequency                                       50/60Hz
Rated test voltage                          3kV AC. (1 min)
Rated short-time thermal current(Ith)                 60In
Rated dynamic current, (Idyn)                         2.5Ith
Rated voltage,(Um)                                0.72Kv AC.
Continuous overload,(Id)                                  1.2In
Operating temperature                          -10°C~50°C
Housing self-extinguishing class                        VO
Safety factor                                                  FS 5
Secondary current                                        5A/1A









....
