Current Transformer/Instrument Transformer/Mutual Inductor MSQ, MSQ-40

Specifications

1,CE, ROHS approval
2,Found in 1992
3,Professional manufacturer
4,ISO9001,ISO14001
5,Export to Europ, America, Asia, Africa

1.Description
 A range of (8 frames) classic plastic case current transformer, low cost, rich range can match most requirements internationally.



2.Feature
Two built in fixing methods:1 side base; Busbar mounting
Transparent terminal cover
Primary current up to 6000A



3. Specification

Rated Frequency                                                50/60Hz
Rated test voltage                                               3kV AC. (1 min)
Rated short-time thermal current(Ith)                    60In
Rated dynamic current, (Idyn)                              2.5Ith
Rated voltage,(Um)                                             0.72Kv AC.
Continuous overload,(Id)                                     1.2In
Operating temperature                                          -10°C~50°C
Housing self-extinguishing class                            VO
Safety factor                                                        FS 5
Secondary current                                               5A/1A







MSQ series: MSQ-B, MSQ-30, MSQ-30T, MSQ-40, MSQ-60, MSQ-85, MSQ-100, MSQ-125















4. Packing show



5. Company show









6. Production series







....
