Home > Electrical & Electronics > Breaker & Protector > Circuit Breaker > Conventional Air Circuit Breakers DW17,DW45
US$ 790 - 10,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Dixsen
Model Number:
DW45-3200
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Conventional Air Circuit Breakers DW17,DW45US$ 790 - 10,000MOQ: 1 Piece -
Universal Circuit Breakers(DW45 ACB)US$ 790 - 10,000MOQ: 1 Piece
-
SW45 4000A Air Circuit BreakerUS$ 790 - 10,000MOQ: 1 Piece
-
SW45 2000a Air Circuit BreakerUS$ 790 - 10,000MOQ: 1 Piece
-
SW45 3200A Air Circuit BreakersUS$ 790 - 10,000MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
Dixsen
Model Number
DW45-3200
Type
Vacuum
Poles Number
Other, 3P,4P
Specifications
A.Founded in1980B.CE,ROHS,SGS,UL,KEMA,VDE,TSE,CB
C.ISO9001,14001
D.manufacturer
E. 430 employees,15000 square meter factory
SW45 (DW45 series) intelligent air breaker is applicable for distribution network of AC50Hz,rated voltage of 400V and 690V,and rated current of 630A - 320A,to distribute electric energy protection circuit and prevent power equipments from harm of overload,under-voltage,short circuit and single-phase earth etc.Provided with intelligent protecting function and precise selective protection,breaker can enhance the dependability of power supply and avoid unwanted power cut.
Specifications:
| Frame size rated current inm(A) | Rated current InA | Rated insulation voltage(v) | Rated limit short-circuit breaking capacity lcu(kA) | Rated operating short-circuit breaking capacity lcu(kA) | Rated short-time withstand current lcw kA(1s) | ||
| 400V | 690V | 400V | 690V | ||||
| 2000 | 630 800 1000 1250 1600 2000 | 690 | 80 | 50 | 50 | 40 | 50 |
| 3200 | 2000 2500 3200 | 100 | 65 | 65 | 50 | 65 | |
| 4000 | 3200 3600 4000 | 100 | 65 | 65 | 50 | 65/80 | |
| 6300 | 4000 5000 6300 | 120 | 80 | 80 | 70 | 85/100 | |
....
