Specifications
test atomization qualityseal of needle valve
test seal of needle
fast delivery
Pressure range:0-60MPa
HY-1 Nozzle Tester
Gold product!!!
Professional tester for fuel injector nozzle!!
ISO 9001:2008 and CE Certificate!!
Nozzle tester is used to calibrate the injection pressure, fuel atomization, injection angle and tightness of the needle valve lf the diesel injector assembly to ensure good power performance and
Type |
Pressure gnge range (MPa) |
Overall dimensions L×W×H(mm) |
Capacity of fuel tank(L) |
Largest pressure Tested(MPa) |
Net weight (Kg) |
NT-1 |
0~60 |
320×290×510 |
3.5 |
40 |
16 |
Technical Parameter
1. Diameter of pressure gauge: 150mm
2. Pressure gauge range: 0∼60MPa
3. Pressure gauge accuracy rating: 1.6
4. Largest tested pressure: 60MPa
5. Capacity of fuel tank: 3.37L
6. Overall dimension (L×W×H):315mm×285mm×490mm
7. Net weight: 30Kg
8. Fixture included
