HY-WKD Distributor Pump Test Bench Computer Control

Name: HY-WKD Distributor Pump Test Bench Computer Control
Brand: Haiyu
SKU: 114684755
Availability: InStock

Taian Haiyu Machinery Co., Ltd.

5Yrs

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Type:

Engine Analyzer

Voltage:

220v/380v

Power:

11kw

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Type Engine Analyzer

Voltage 220v/380v

Power 11kw

Certification ISO9001:2008

Place of Origin Shandong, China

Brand Name Haiyu

Model Number HY-WKD

Specifications

1.fuel injection pump test bench
2.distributor pump test bench
vide operating video
4.low noise
5.easy operation

high quality , lowest price, fast delivery

what are you waiting for?

HY-WKD fuel injection pump test bench

Power	11KW/15KW
Speed Range	stepless frequency conversion, multi-gear speed overhead, speed :50-400 circle/min or at will
Number of station can be debugged	12
Fuel supply	0-0.4MPa(low pressure) 0-4MPa(high pressure)
Overall dimension	length:2100mm width:700mm height:1470mm
Net weight	1000kg
Function	debugging the uniformity and quantity of the oil supply of each cylinder in injector pump
	debugging the test point and interval angle of oil supply of injector pump
	debugging the performance of different speed governor
	checking the tightness of injector pump
	Testing the quantity of oil return of distribution pump
	checking pressure compensator of distribution pump
	measuring the pressure of pump chamber
	measuring the advance angel
	measuring the travel of gear lever
