10600nm laser equipment co2 fractional
Model#:Yinhe-3000
Working theory
With the CO2 laser light passes through the micro optics lens array to penetrate the skin with tiny thermal channels. This creates an ablative and thermal effect in only these channels a micro-injury without disturbing the surrounding tissue. The tissue surrounding the micro-injury sites (about 15-20 percent of the treatment area) start the process of healing. As collagen remodels, skin tightens and scars improve. The intact, undamaged skin around the treatment site is what promotes quicker healing for a faster recovery.
Application Range
1.Full facial refacing, improving new skin generation
2.Wrinkle removal, tightening aging skin
3.Acne scar improvement
4.Scald recovery, surgical scar recovery
5.Color spot/Pigment improvement
6.Photo damage skin recovery
7.Begign neoplasm and melanotic nevus removal
Technical Parameters
| Basic information | Wavelength | 10.600 nm |
| Pulsed radiofrequency | 0.530 W | |
| Ultrapulse | 1.Max power: 120W 2.Pulse width:200 to 500μs s is optional | |
| Pulse | Average power: 30W | |
| Matrix mode | Scan pattern | Square, rectangle, round, triangle, oval, 6-diamond shape, line or customized graphics |
| Scan pattern size | 0.1x0.1mm - 20x20mm | |
| Dot quantity | 400 dots at most | |
| Working state | ultrapulsed mode; | |
| Scan mode | free scan; Sequence scan; maximum distance scan | |
| Pulse duration | 0.1-10ms | |
| Spot distance | 0.1-2mm | |
| Pulse energy | 1mj to 100mj is optional for each dot. | |
| Technical specification | Laser apparatus | Sealed off laser device stimulated by direct current |
| Condenser focus | f=50mm | |
| Beam divergence angle | 0.3 mrad | |
| Spot size | >= 0.2mm at the focus | |
| Radiation time / Interval time | 0.01 1 s | |
| Aiming beam | 635nm infrared ray | |
| Beam transport device | 7 articular arm | |
| Net weight | 47 kg | |
| Machine size | 43x57x118cm | |
| Power supply | 230V/110V | |
CO2 laser system
The CO2 laser with a specific wavelength of 10.6 nm can be absorbed by human body tissue (no matter what color the skin is) by nearly 100%. Through laser emitter, the micropulsed laser beam shoots on the target skin in nanometer level to achieve a controllable precise treatment .The dimension of shooting area only can be measured in nanometer, which is precise enough for operators to control and adjust the treated depth andlayer according to the clinical diagnosis.
The energy of CO2 laser is even and steady. Its focused energy aims only at target tissue without any injury to surroundings. It is the heat and electromagnetic effect of the laser that people use to conduct non-blood or less-blood cutting, cauterizing, gasification and accurate microsurgery so as to avoid skin burnt. During the treatment, biochemical reactions of optical-thermal accelerate collagen reproduction and skin recovery,after exfoliation of the tiny scar; fresh and smooth skin can be regenerated. The device outputs invisible laser. In order to operate with more ease, red semiconductor laser has been added to indicate.
Technology Advantages
1.True micro ablative skin resurfacing.your first option for ablative laser treatment.
2.Remove multiple kinds of ecthymata through carbonization and vaporization.Various applications can be achieved in many surgical operations by selection of different treatment hand-piece.
3.The characteristic of blood coagulation is of great benefit,especially for surgical operations in large area.
4.It have three laser output moods optional:Super mood,Continuous mood and Fractional Mood with various spot sizes and patterns,which makes it more accurate for treatment of different skin types.
5.US-imported RF-CO2 laser source,more even and steady laser
6.Various and customized setting for all skin type.All area of body.
7.Proven and instant results
8.Fast treatment without downtime.
Before and after photo
Photo of the fractional Co2 laser machine----Yinhe-3000
Accessories List of Yinhe-3000
Technology of Ultrapulse
Mainly let the original average output of the laser energy concentrated in a very short period of time then output, due to the high pulse power, short time, and more round spot, the pressure on the surface from laser heat transfer effects is low (small heat-affected zone).
Shipping Way
DHL.UPS.TNT.FedEx.
Usually it will take about 5-7 working time to come to your door.
Training
Detailed user manual,CD and online education.
Warranty
We have one year warranty,two year update warranty and lifetime maintenance.
1.Within one year,if there is some accessory going wrong,we will send you the accessory at once,free of charge.
2.Within one month,if the machine is of any big fails,we will send you a new machine.
3.Within one year,if you send back the equipment for repair,we will be responsible for the repair,including the changes of accessories;Bothof them are free of charge.
4.If the buyer has any questions from our technical department,we can supply on-line service.
Questions You May Concern
Q1. Is it a reliable company?
Zhejiang Lasy Sci.&Tech. Co., Ltd. Is an large professional company engaging in research&development as well as production and sales of medical and beauty equipment in a early time in China. We have a professional team integrating with optics, machinery, electricity and medicine, to keep us ahead on in this field. Lasy factory covers 1500M2 and has more than 60 employees. All provide is a reliable manufacturer and supplier.
Office Address:No.207 JingFa Road,Yiwu City,Zhejiang Province,China.
Factory Address:No.561 Chengdian Road,Yiwu City,Zhejiang Province,China
Q2: What about the delivery?
We can offer the door to door services by air or by sea, just depend on your actual request. Such as DHL, UPS, TNT, FEDEX.EMS… by air; and the sea transportations.
Q3: What’s the delivery time?
5-7 days.
Q4: What’s package?
Shockproof,Strong and beautiful aluminum alloy case/carton case/wooden case.
Q5: Do you have any timely technology supports?
We have a professional technology supporting team for your timely services. We prepare the technical documents for you, also you can contact us by telephone, webcam, online chat (MSN, skype, yahoo manager,alibaba trade manager …).
Q6: What’s the payment method?
T/T, WESTERN UNION,PAYPAL. ESCROW
Q7: If the machines broken during the shipment, will you support us?
Generally our customer will purchase the insurance before shipment, avoid any money lost from rough transportation.We will help you to solve the claims with the insurance companies to collect your money back in time.
Certificate
Company Show
Factory Show
Exhibition Show
We look forward to a mutually profitable and healthy business relationship with you!
Welcome to China!
Welcome to Lasylaser!
Application:
1. Application Range of Fractional treatment handpiece
a. Large pores, Fine lines, Skin tightening and whitening, Skin loosen(Deep Wrinkles), Stretch marks.
b. Various Scars: Burn Scars, Acne Scars, Surgical Scars and Keloid;
c. Reconstruction of photoaging skin.
2. Application Range of Incision Handpiece
a. Via multiple handles it can be adapted to Gynecology, ENT, Neurology and general surgery
b. In cosmetic surgery, it can be adapted to incisions for Blephaplasty, Skin Tags and Ingrow Nails, Compound Nevus and Intra Dermal Nevus etc
