Common Rail Injection Test Stand HY-CRI200A Test Bench , Easy Operation

Name: Common Rail Injection Test Stand HY-CRI200A Test Bench , Easy Operation
Brand: Haiyu
SKU: 114642169

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Type:

Engine Analyzer

Voltage:

220v/380v three phase four wire

Power:

2.2KW

Taian Haiyu Machinery Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Type Engine Analyzer

Voltage 220v/380v three phase four wire

Power 2.2KW

Certification ISO9001:2008 CE

Place of Origin Shandong, China

Brand Name Haiyu

Model Number HY-CRI200A

Specifications

1HY-CRI200A test stand
2Cast iron operation platform
3secondary filter:10um
4Delixi electrical component
5.fast delivery

HY-CRI200A Common Rail Injection Test Stand

CE certificate, ISO9001 certificate

Name and Model	System	Specification Details	Remarks
HY-CRI200A High Pressure Common Rail Injector Test Bench	Main Engine System	2. The main frame is aviation aluminum structure and cast iron operating platform. 3. Its control type is automatically computer control and display by screen. 4. The accuracy of weighing oil digital readout (weighing transducer) is 0.1ml. 5. Its revolving speed range is 0~1500r/min (adjustable) (digital readout).	Furniture Included
	Oil Circuit System	1. The high pressure pump is BOSCH, CP3.3, max 200Mpa. 2. Rail pipe is BOSCH. 3. The rail pipe is controlled by automatically closed cycle, and pressure display (accuracy±0.1Mpa) with overpressure protection. 4. Oil temperature (adjustable) is controlled automatically heated by heating pipe and radiated though radiator. 5. Its filtering type is secondary filter.
	Electrical equipment	1. It has built-in electrical box and convert box. 2. Short-circuit protection.
	Data base	It has more than 600kinds of standard build-in data, which can be upgraded.
	Testing fuel injector	1. It can test 1 fuel injector every time. 2. It can test 6 fuel injectors at most in the same time (Price is extra). 3. The types it can test are BOSCH, DENSO, DELPHI, and SIEMENS.
	Overall dimension	Length: 1000mm, Width: 850mm, Height: 1430mm
	Weight	Net weigh: 400kg.
