HY-CRI200A Common Rail Injector Test Bench ( Low Noise )TEST EQUIPMENT
- Qingdao
- Money Gram Credit Card
You May Like
-
HY-CRI200A Common Rail Injector Tester( Test Bench )
-
New-PQ1000 Common Injector Test Bench, CE Certificate ( Wood Package )
-
PQ1000 Test Bench(for Bosch Delphi Denso)test Equipment , Wood Package
-
PQ1000 Test Bench(for Bosch Delphi Denso)test Equipment , Wood Package
-
PQ1000 Test Bench(for Bosch Delphi Denso)test Equipment , Wood Package
-
PQ1000 Common Rail Injector Test Bench( Ultrosonic Cleaning Injector )
Product Details
| Type | Engine Analyzer | Voltage | 220V/380V | |
| Power | 2.2KW | Certification | ISO9001:2008 | |
| Place of Origin | Shandong, China | Brand Name | HAIYU | |
| Model Number | HY-CRI200A |
wood package
Product Description
Specifications
1.HY-CRI200A common rail injector test bench2.overpressure protection
3.stable rail pressure
good reputation
HY-CRI200A high pressure common rail injector test bench
CE certificate and ISO9001
Introduction
HY-CRI200A type high pressure common rail injector test bench.600kinds of standard statistics of common rail injector are built in. with high accuracy flow test detection equipment. It can automatically test the oil injection and oil return under the circumstance of sealing, full load, idle operation, preinjection. The test bench with high compacted structure can transmission smoothly, is reliable and operated simply, small size for easy mobility.
Main function:
1. Variable frequently drive pump serves the common rail BOSCH CP3.3 and the maximum pressure is 200Mpa. Automatic closed-loop control rail press accuracy displayed is± 0.1Mpa.
2. Adjustable inject frequency and time.
3. Built-in standard database of common rail injection pump, data can be update and added freely by users.
4. The standard database contains the waveform control data of all types of injection pump, and it can output the standard waveform control signal to the injection pump.
5. It can test BOSCH, DENSO, DEPHI and SIEMNES.
6. Industrial computer motherboard and embedded operating system Windows XP. It is screen displays basic status such as: the rail pressure, temperature ,host operation, speed, heating, cooling, also has some windows for fuel injection pump test, common rail test, fuel measurement, parameter setting, injection waveform, problem analysis and data reports.
7. Touch screen operation, easy to learn and use
8. Oil injection and oil return are automatically detected and clearly displayed on the large screen
9. Test data reports can be generated, stored and print (can be choose)
10. Testing the sealing of the common rail injection pump
11. Testing the condition of idle speed
12. Testing the condition of pre-injection
13. Testing the condition of the atomization quality
14. Function of high pressure cleaning of the injector
Company Profile
Taian Haiyu Machinery Co., Ltd. is located at the foot of famous Mountain Tai in the north development zone of Taian City which is between spring town - Jinan and the hometown of Confucius - Qufu. We enjoy convenient transportation and Taian City is at the junction of Beijing-Fuzhou Highway and Beijing-Shanghai Highway. Taian Haiyu Machinery Co., Ltd. is a modern technological company combing research, production, sale and service. We have a number of engineers working on designing and producing engine testing equipment and some sophisticated staff members specialized in computer software and hardware design. In recent years, we have cooperated with research institutions of universities. Our company succeeds in researching new series of HY injection pump test benches and injector test benches. Functions of the equipment have reached the internationally advanced level. We fully meet the needs of customers. Besides, we can also design particular testing benches according to customers' requests. In order to meet the requirements of lowering exhaust in diesel engine field and achieve European III standard, our company researches and develops common rail system test benches which have excellent functions and high accuracy. Our test benches have been widely used by internal engine industry and are exported to more than 30 countries and regions, including Asia, Africa and America. Our company also has long-term cooperation with Guanghua Gas and imports SMC gas meter boxes, stainless steel meter boxes, cold plates and other metal products. We adhere to the principle of "sincere cooperation" and warmly welcome customers from all over the world to visit us. We hope that you can work together with us for a beautiful future.
