Taper Grid Coupling
Description
MERITS 1. When overload occur, grid breaks and prevents breaking of the shaft or machinery part connected. 2. When the parallel misalignment is too severe, the relating machine is protected by the virtue of shearing Grid or Tooth. 3. The life of parts (Mechanical Seal and Bearing, etc) can be extends to twice or more. 4. Quick installation and easy maintenance reduce labor cost and downtime costs. 5. Grid coupling is interchangeable with international industry standard. 6. It always transmits the power full(100%) under low noise. 7. You can use it continually at cheaper replacement cost by changing damaged parts only.
Tapered Grid Coupling
The steel tapered grid coupling is similar in nature to a steel gear coupling, except the connecting sleeve is replaced by a flexible chrome-vanadium alloy leaf spring grid. The steel hubs are cut with profiled slots, allowing the grid to engage circumferentially. The grid "springs" deflect under torque, distributing the peak torque load over a large angle of rotation. The inherent property of torsional softness allows the coupling to absorb shock loads.
Spring coupling,dampling is good,long life to withstand changes in load range,start safe,efficient and reliable transmission.
Feature:
1.Material:60SiaMnA(SAE9260) ,50CrVA(SAE6150)
2.Surface treatment:bluing,phosphatization,galvanization,electrophresis and mechanical and etc.
3.Good quality and long service life.
