Home > Products > Pipeline welders > DPS-500 Digital Double Pulse MIG/MAG Welding Machines/welder
DPS-500 Digital Double Pulse MIG/MAG Welding Machines/welder
- 200 Set / Sets per Month
- Shanghai Tianjin Chengdu
- T/T
Product Details
Condition: | New | Place of Origin: | Sichuan, China | Brand Name: | xionggu |
Model Number: | DPS-500 | Arc Current: | 400A | Rated Duty Cycle: | 100% |
Motor Type: | DC Motor | Dimensions: | 400mm*700mm*500mm | Usage: | pulse mig mag welding |
Voltage: | 400A/36V | Power(W): | 15KVA | Certification: | CE CCC ISO |
Warranty: | one year | After-sales Service Provided: | Overseas third-party support available |
Product Description
DPS-500 Series Digital Pulse MIG/MAG Welders
PSTTM (Precision Short-circuit Transition)
DPS-500 Series
- Carbon steel’s PSTTMand pulse welding
- Metal powder flux cored wire’s PSTTM and pulse welding
- PIPE/ SMAW SOFT(STICK)
- FCAW (optional)
- Aluminum or aluminium-magnesium alloy’s pulse/double-pulse welding
- Optional external controller interface
Working Conditions: Ambient temperature -40~55℃;Altitude 4000m.
Accessories: XG series wire feeders,RWG series MIG/MAG solid wire torch.
Supportting a variety of materials’ pulse and precise short circuit (PSTTM, Precision Short - circuit Transition) welding, also supports material such as aluminum alloy ’ s double pulse welding based on an advanced fully digital welding system platform;
50kHz switching frequency and the integration of DC bus-bar structure bring out an excellent dynamic performance of power source;
The welder has high reliability, long lifespan, extensible remote monitoring, production quality management and other functions;
The DPS-500 Chinese display panel is designed to be easy setting and operation.
DPS-500 G:
For general application
Carbon steel’s PSTTM and pulse welding
Aluminum or Aluminium-magnesium alloy’s pulse/double-pulse welding
SMAW SOFT(STICK)
DPS-500 P:
For pipeline welding
PSTTMweldingwith metal powder flux cored wire for root pass.
Pulse welding with metal powder flux cored wire for filling and capping.
PIPE/ SMAW SOFT(STICK)
FCAW (optional)
DPS-500 A:
For Automatic welding
Supporting a variety of materials’ pulse and PSTTMwelding
External controller interface for automatic welding.
Main Technical Parameters
Model | DPS-500 A | DPS-500 P | DPS-500 G | |
Product ID | 4087010000 | 4088010000 | 4083010000 | |
Input power Phase/Voltage/Hertz | 3 phase 380V±20% 50-60Hz | |||
Rated Input Power | 23kVA | |||
Rated Input Current | 34A | |||
Rated Output Current/Voltage | 400A/36V | |||
Rated Output Duty Cycle | 100% | |||
Max.Open-circuit Voltage | CV | 55V | ||
CC | 55V | |||
Output Voltage Range(CV) | 15.25-34V | |||
Output Current Range(CC) | 25-400A | |||
Cooling | Air-cooling | |||
Weight | 62.5kg | |||
Dimensions(W×D×H) | 400mm×700mm×500mm |
