rj45 plug with transformer and led female right angle wifi modem connector

rj45 plug with transformer and led female right angle wifi modem connector

Material:

1,Housing: Nylon PBT(UL 94V-0 )

2,Contacts:

   Flat Pin: 0.35mm thickness phosphor bronze plated with 3u''/

                6u"/15u'' /30u'' /50u'' min hard gold over 2.45um(100u'')nickel

3,Shielding: 0.2mm thickness brass with nickel plated

Specification Characteristic:

1, Port:1

2,Position Number: 8 positions

3,Contact Number: 8 contacts

4, Shielding: Non-Shielded/Shielded with EMI finger

5, Magnetics: Schematic available

6, LED: Without LED/LED (Different colors of LED option available)

7,Leg/tab: None-Leg/back leg 3.05/front Leg 3.05/fornt Leg 3.68

8,PEG: None/ 1 peg/ 2 peg/ 3 peg

Feature:

*Shielded RJ-45 connector with intergrated 10/100 or Gigabit Ethernet magnetics

*Complies with IEEE 802.3 standards and all 10/100/1000 Ethemet specifications

*Compatible with a variety of 10/100 Base-T transceiver lcs

  and Gigabit Ethernet transceiver lcs

*Jack cavity conforms to FCC rules and regulation Part 68 subpart F

*Intergrated design conserves valuable board space

*Minimum interwinding breakdown voltage of 1500 Vrms

*Adaptable, modular dasign provides higher reliability

*Operating temperature: 0℃ to +70℃

*Storage temperature: 40℃ to +85℃

Jacks Shielded With Filter
