Packing Machine Part Brad Cigarette P-180 Spare Part
PRODUCTION INFOMATION
P-180 Cardboard Packet Packing Line is used to pack the cigarettes
in length of 84-100mm with different diameters, in different arrangement. It can automatically complete the operations of hinge-lid cardboard packet packing, packet film wrapping, carton packing and carton film overwrapping. And its packing speed is 180 packets per minute.
The line has slow starting, automatic protecting, testing, ejecting and indicating fault functions, and features, and features easy operation and convenient maintenance. It is the ideal cardboard packaging equipment. About the standard of the products, we can make the various according to the customers' requiems, for example 10pcs/box , 12pcs/box , 16pcs/box etc.
MAIN PARAMETER
Operating speed: 180 packets/min
Cigarette standard
Length: 84mm-0.5mm
Circumference: 24.5±0.3mm
Packet outside dimension: (L×W×H)87.5×56×23.5mm(Collation7×6×7)
Carton outside dimension: 283×90×48.5mm
Power consumption: 9.92Kw
Weigh: 6150kg
Outside dimension(L×W×H): 8600×6700
SPECIFICATION
Requirements for raw materials : | |
Transparent paper | |
Material |
Sealing type polypropylene film biaxial stretching (GB/12026-89) |
Quantitative |
19-23g/ m2 |
Width |
358mm |
Thickness |
0.02-0.025mm |
Core hole diameter |
75mm |
Drawstring | |
Strong resistance to stretching, breaking tension of not less than 10N, put volumes should be straight, not twisted, self-adhesive materials. | |
Width |
2.5mm |
Roll diameter |
28mm |
Quantitative |
40-70g/m2 |
