Specifications
high pressure pumpMax. Pressure:100bar (10MPa);
Oil Hydraulic Drive;
20 years experience;
ISO
| Output | 60 L/min (3.6m3/h) |
| Working pressure | 4 Mpa (40kgf/cm2) |
| Working cylinder Dia. | 75mm |
| Piston stoke | 85mm |
| Piston speed | 85 times/min |
| Inlet hose Dia. | 42mm |
| outlet hose Dia. | 38mm |
| Motor Power | 5.5 KW |
| Weight | 210kg |
| Dimensiton (l8w*h) | 1280*485*645 |
High Pressure Pump SG 60/40 is a piston grouting pump for the professing of middle pressure grouting
The machine is suitable for grouting with either of single slurry and two different slurries. It can be widely use for tunnels, slope, mining, bridge and all sorts of underground engineering etc
Main Technical features
1) Single piston double acting
2) Gear & Vee belt transmission makes this pump high mechanical efficiency and working reliability
3)Integrated valve house and ball valve, together with compact structure
4) can complete double slurry grouting and single slurry grouting
Zhengzhou Sincola Machinery Co.,Ltd is a stated- designated manufacturer and exporter of road and building construction machineries. We are the one of the big manufacturer and supplierin China .
Our products are Shotcrete machinery and Concrete Pump,Plaster Machine,Mortar Pump,Spraying Machine,Industrial Hose Pume,Grouting Pump,Automatic rendering machine. Also we are the manufactur,supplier and exporter of semi-automatic and full-automatic dry motar mixing plants.large and medium size of concrete mixing plants.
Our company engaged an international expert guidance, the study has been made a number of patents.Our technical experts from the United States, Germany, Italy and other multi-national team of experts.
Our products are well known to international market such as Russia, UzbekistanRussia,Uzbekistan,Cyprus,Algeria,Cameroon,Macedonia,Malaysia,Austrialia,Yemen,Oman etc.
Our products have widely been applying in construction, railway and super highway engineering, underground engineering, tunneling, mining operation,hydropower projects and slope stabilization.
Service:
We keep the service idea of "creat more value to customers" , treating our customers with all our hearts, and meantime lawfully running it. Our customers distribute in over 120 countries in Asia, Europe, Middle east,Oceania and America. We apply our professional knowledge and full global service capability to ensure the best results for our customer's business...
Any questions, Pleasecntact me...
