Specifications
Full Hydraulic Electric Cement Grouting PumpOutput:100L/min;
Max. Pressure:100bar (10MPa);
Oil Hydraulic Drive;
Output Capacity: |
0~100L/min |
Max. Pressure: |
10MPa (100bar) |
Clyinder Dia.: |
110mm |
Piston Stroke: |
150mm |
Piston Speed: |
45/min |
Inlet Dia.: |
38mm (1 1/2”) |
Outlet Dia.: |
32mm (1 1/4”) |
Motor: |
E-motor 11kW (15hp) |
Transmission: |
Fluid Drive |
Net Weight: |
580KGS |
Dimensions (LxWxH): |
1505x770x1110mm |
Full Hydraulic Electric Grouting Pump, often work with RM mixer. The idea choice of grouting pump Machine.
SG90 full hydraulic grout pump is a Single cylinder double-acting grouting pump with hydraulic drive, which is a universal high-pressure grouting pump machine is used for grouting in soil, earth foundation stabilization, waterproofing, tunnel lining,underwater foundations , bridge decks , deep well casing, slope line grouting,etc,
- Single piston double-acting
- Oil hydraulic drive
- Compact structure with reliable working
- Ball valve
- Work with Grouting Mixer RISEN RM250/700
Grouting in tunnels, mines, hydro-power engineering, civil engineering, slope stabilization, earth foundation stabilization, underwater foundations , bridge decks , deep well casing, etc.;
Sealing, strengthing and stabilizing of rock and soil.
Zhengzhou Sincola Machinery Co.,Ltd is a stated- designated manufacturer and exporter of road and building construction machineries. We are the one of the big manufacturer and supplierin China .
Our products are Shotcrete machinery and Concrete Pump,Plaster Machine,Mortar Pump,Spraying Machine,Industrial Hose Pume,Full Hydraulic Grouting Pump,Automatic rendering machine. Also we are the manufactur,supplier and exporter of semi-automatic and full-automatic dry motar mixing plants.large and medium size of concrete mixing plants.
Our company engaged an international expert guidance, the study has been made a number of patents.Our technical experts from the United States, Germany, Italy and other multi-national team of experts.
Our products are well known to international market such as Russia, UzbekistanRussia,Uzbekistan,Cyprus,Algeria,Cameroon,Macedonia,Malaysia,Austrialia,Yemen,Oman etc.
Our products have widely been applying in construction, railway and super highway engineering, underground engineering, tunneling, mining operation,hydropower projects and slope stabilization.
Service:
We keep the service idea of "creat more value to customers" , treating our customers with all our hearts, and meantime lawfully running it. Our customers distribute in over 120 countries in Asia, Europe, Middle east,Oceania and America. We apply our professional knowledge and full global service capability to ensure the best results for our customer's business...
