Specifications
Cement Grout Pump injection machineMax. Pressure:100bar (10MPa);
Oil Hydraulic Drive;
20 years experience;
Cement Grout Pump injection machine
Output Capacity: | 0~100L/min |
Max. Pressure: | 10MPa (100bar) |
Clyinder Dia.: | 110mm |
Piston Stroke: | 150mm |
Piston Speed: | 45/min |
Inlet Dia.: | 38mm (1 1/2”) |
Outlet Dia.: | 32mm (1 1/4”) |
Motor: | E-motor 11kW (15hp) |
Transmission: | Fluid Drive |
Net Weight: | 580KGS |
Dimensions (LxWxH): | 1505x770x1110mm |
Pressure Cement Grout Pump injection Machine, often work with RM mixer.It is an idea choice of Cement pressure grouting pump Machine. SG90 full hydraulic pressure grouting pump machine is a Single cylinder double-acting grouting pump with hydraulic drive, which is a universal high-pressure Cement grouting pump machine is used for grouting in soil, earth foundation stabilization, waterproofing, tunnel lining,underwater foundations , bridge decks , deep well casing, slope line grouting,etc.
- Single piston double-acting
- Oil hydraulic drive
- Compact structure with reliable working
- Ball valve
- Work with Grout Mixer RISEN RM250/700
Cement Grout Pump injection machine in tunnels, mines, hydro-power engineering, civil engineering, slope stabilization, earth foundation stabilization, underwater foundations , bridge decks , deep well casing, etc.;
Sealing, strengthing and stabilizing of rock and soil.
Zhengzhou Sincola Machinery Co.,Ltd is a stated- designated manufacturer and exporter of road and building construction machineries. We are the one of the big manufacturer and supplierin China .
Our products are Shotcrete machinery and Concrete Pump,Plaster Machine,Mortar Pump,Spraying Machine,Industrial Hose Pume, Grout Pump Machine,Automatic rendering machine. Also we are the manufactur,supplier and exporter of semi-automatic and full-automatic dry motar mixing plants.large and medium size of concrete mixing plants.
Our company engaged an international expert guidance, the study has been made a number of patents.Our technical experts from the United States, Germany, Italy and other multi-national team of experts.
Our products are well known to international market such as Russia, UzbekistanRussia,Uzbekistan,Cyprus,Algeria,Cameroon,Macedonia,Malaysia,Austrialia,Yemen,Oman etc.
Our products have widely been applying in construction, railway and super highway engineering, underground engineering, tunneling, mining operation,hydropower projects and slope stabilization.
Any questions, Pleasecntact me...
