Home > Products > Construction Machinery > portable concrete batching plant,low cost concrete batching plant,price of concrete batching plant
portable concrete batching plant,low cost concrete batching plant,price of concrete batching plant
- 5 Set / Sets per Month
- Qingdao Shanghai
- T/T Credit Card
Product Details
Condition: | New | Power Type: | Electric | Place of Origin: | Henan, China |
Brand Name: | Sincola | Model Number: | HZS60 | Power(W): | 120Kw |
Dimension(L*W*H): | 33.8m*14.8m*10.8m | Weight: | 48T | Certification: | ISO9001 |
Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Nude packing, or as per your requirements
Product Description
Model | HZS60 |
Rated Productivity | 60m3/h |
Main Mixer | JS1000 |
Max. Aggregate Diameter | 80mm |
Capacity of Aggregate Bin | 3×8.38m3 |
Aggregate Conveying Mode | Flat Belt Conveyor |
Aggregate Weighing Precision | 3X 3000Kg ±2% |
Cement Weighing Precision | 1500Kg ±1% |
Fly Ash Weighing Precision | 600Kg ±1% |
Water Weighing Precision | 600Kg ±1% |
Additive Weighing Precision | 50Kg ±1% |
General Power | 120Kw |
Total Weight | 48T |
Outline dimension (L*W*H) | 33.8m×14.8m×10.8m |
Discharging Height | 3.8 m |
Powder Silos (for customers choice) | The capacity and number of silos as well as the configuration of silo accessories vary with customers’ demands. |
Screw Conveyors (for customers choice) | Usually, φ273mm screw conveyors are used. |
1. twin shaft concrete Mixer JS1000
2. aggregate batcher PLD1600 with 3 storage bins;
3. cement silo: 100T boltd type (it depends on the customer's choice);
4. screw conveyor: 273mm*8m
5. cement, water, fly ash and additive scales;
6. computer controlled automatic control system.
HZS60 concrete batching plant is composed of material supply,batching system,mixing,electrial control and steel structure. concrete batching plant is ideal concrete equipment for building project, building ground and precast product factory. The main characteristic is:
It adopts knockdown structure and blocking. It is combine mode.
concrete batching plant adopts JS1000 concrete mixer, it has good mixing quality and high efficiency.
concrete batching plant is measuring nicety and high produce efficiency.
The forced water supply system spray equably and has washing function for the mixing system.
concrete batching plant It adopts the ectctrial weigher to measure all the aggregate,cement,water,liquid additive.
The electrical system adopts import parts and has credibility performance.
Zhengzhou Sincola Machinery Co.,Ltd is a stated- designated manufacturer and exporter of road and building construction machineries. We are the one of the big manufacturer and supplierin China .
Our products are Shotcrete machinery and Concrete Pump,Plaster Machine,Mortar Pump,Spraying Machine,Industrial Hose Pume,Grouting Pump,Automatic rendering machine. Also we are the manufactur,supplier and exporter of semi-automatic and full-automatic dry motar mixing plants.large and medium size of concrete mixing plants.
Our company engaged an international expert guidance, the study has been made a number of patents.Our technical experts from the United States, Germany, Italy and other multi-national team of experts.
Our products are well known to international market such as Russia, UzbekistanRussia,Uzbekistan,Cyprus,Algeria,Cameroon,Macedonia,Malaysia,Austrialia,Yemen,Oman etc.
Our products have widely been applying in construction, railway and super highway engineering, underground engineering, tunneling, mining operation,hydropower projects and slope stabilization.
Service:
We keep the service idea of "creat more value to customers" , treating our customers with all our hearts, and meantime lawfully running it. Our customers distribute in over 120 countries in Asia, Europe, Middle east,Oceania and America. We apply our professional knowledge and full global service capability to ensure the best results for our customer's business...
Company Profile
Zhengzhou Sincola Machinery Co., Ltd. is a high-technology, modern enterprise professionally engaged in the R&D and manufacturing of full automatic dry mortar plant and semi automatic dry mortar production line 1-5tph dry mortar plant and shotcrete machine plaster machine and mortar pump,wall rendering machine,concrete pump etc.
