Home > Manufacturing & Processing Machinery > Mixing Equipment > Concrete Mixer > Concrete Mixer With Diesel Engine

Concrete Mixer With Diesel Engine

Name: Concrete Mixer With Diesel Engine
Brand: SINCOLA
SKU: 114465007
Availability: InStock

Concrete Mixer With Diesel Engine thumbnail-1

Concrete Mixer With Diesel Engine photo-1

US$ 1,000 - 2,800 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Henan, China

Brand Name:

SINCOLA

Contact Supplier Request Quote Chat Now

Zhengzhou Sincola Machinery Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI TIANJING QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Henan, China

Brand Name SINCOLA

Model Number JZR350

Mixing Power 12HP

Charging Capacity 350L

Reclaiming capacity 560L

Speed of Mixing Drum 16r/min

Water Supply Mode Auto

Outline Dimension 31000*2220*3070mm

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Diesel Engine Concrete Mixer
Discharging Volume:350L
Feeding Capacity:560L
Productivity:10-14m3/h
ISO9001,CE

Technical Parameters

Model	JZR350	JZR500
Capacity of loading	500L	750L
Capacity of discharging	350L	500L
Water tank	110L	140L
Capacity per hour	10-14 m3/h	20-26m3/h
Drum rotating speed	13r.p.m	13r.p.m
Max.towing speed	20km/h	20km/h
Power source	Diesel engine water cooler,single cylinder with battery starter
Power	CHANGFA 16HP	CHANGFA 18HP
Mixing time	46s
Dimensions	31000×2220×3070mm	3750×2240×3800mm
Weight	1850kg	2150kg
Hopper lifting model	Wire rope hoist hopper	Wire rope hoist hopper

Product Description

Application Of Diesel Engine Concrete Mixer

Diesel engine concrete mixer machine is used for mixing plastic and low-fluidity concrete, each time stirring 0.35m3 concrete (refer to the volume after tamping), production rate is 12~14m3/h, applying to most small and medium construction projects, roads, bridges, water conservancy and the concrete plants.Diesel Engine Concrete Mixer.

Characteristic Of Diesel Engine Concrete Mixer

Diesel Engine Concrete Mixer is specially designed for some remote areas without electricity to achieve mechanized construction. The principle is the existing JZC350 concrete mixer is installed a diesel power generation system, and this system can supply electricity power to make sure the normal running of mixer. The generating system's out power is 15KW, so it can also supply extra part of electricity power to other small devices, as concrete vibrators and lighting equipments, while it's keeping the mixer's operation.In addition, the machine can also match the external power directly, achieves diesel-electric dual-use.

Features of Diesel Engine Concrete Mixer

Adding a water pump for water circulation between water tank and water radiator,it keeps the water temperatures stable Removing the air sucking point from the back to the front to reduce its sucking dust ,it will be helpful to prolong the service life of the engine.Diesel Engine Concrete Mixer is a bipyramid reversal discharging self-loading concrete mixer, the mixing drum's forward rotation is mixing, reverse rotation is discharging. The machine has the benefits of simple structure, reliable, good mixing quality, high efficiency, light weight, and easy manipulation of maintenance, so it is more advanced models of concrete mixers. Because outfitting with a diesel-powered engine, it is more applicable to the remote areas and the wild which have no electric power supply.
