Specifications
1.energy saving 30%2.Competitive Price
3.15Years Manufacturing Experience
ft-surface circular tooth gearbox
Speed reducter in ZD series/gear box/gearbox
Introduction
ZD cylindrical gearbox for concrete mixer is single stage according to the country standard of JB/T8853-2001
ZD Serial gear reducer is generally used for all kinds of fields.
1.It used the highly strength alloy steel gear that should be cementite,quenching and heat treatment.The strength of hard tooth surface can reach to HRC58-62.All the gears of reducer need spur technics.So it has high precision and definition.
2.It has high transmission efficiency;
3.It runs placidly and the noisy is low.
4.The volumn is small,the weight is light,the service life is long,the torque is large.
5.It's easy to remove and fix up.
Gear reducer scope
1. Tigh speed shaft rotation is not allowed more than 1500 r / min.
2.The gear transmission is not allowed more than the peripheral speed of 20 m / sec.
3.The working environment temperature :-40-45 °C, if less than 0 °C, before the start of oil should be preheated to above 0 °C, gear reducer can be used in both directions running.
Product usage
Our gearbox are widely used in metallurgy, mining, lifting, transporation, construction, chemical, building, light industry, food, conveying machinery, marine, brick-making, ect.
Model
ZD10 ZD15 ZD20 ZD25 ZD30 ZD35 ZD40 ZD45 ZD50 ZD60 ZD70 ZD80
(Shandong. China)Zhangqiu Long Teng Cement Machinery Making Co., Ltd. has become one of the new domestic cement equipment and mining equipment manufacturing enterprises after constructing and developing for 40 years. Main products include complete machines and accessories of ''Dragon Heavy Industry'' brand large and medium-size ball mill, cement rotary kiln, dryer, reduction gear, crusher, roller press, novel biological granulation machine, brick-making machine, etc., and wear-resistant consumable materials, such as steel balls, steel segments, liners, etc.
Why do so many customers choose us?
1. Competitive price and high precision
2. Prefect after-sale service.
3. One year warranty time.
4. 15 years manufacting experience.
5. We can customized gearbox as your requirements.
Payment terms:
Our gearbox is 30% TT in advance+70% balance before shipment or total advance.
Contact Details
Ms. Chris Ji( +86-13864137739)
Zhangqiu Long Teng Cement Machinery Mking Co.,Ltd
Add: Niuyi Industrial Park, Xiuhui Town,Zhangqiu City,Jinan,China
Tel: +86-0531-61328855 Fax: +86-0531-61328855
