Home > Lights & Lighting > LED Interior Lighting > LED High Bay Light > New Products 2013! HOT! 100w High Bay Led Bulb

New Products 2013! HOT! 100w High Bay Led Bulb

Name: New Products 2013! HOT! 100w High Bay Led Bulb
Brand: XINGPU
SKU: 114412629

New Products 2013! HOT! 100w High Bay Led Bulb thumbnail-1

New Products 2013! HOT! 100w High Bay Led Bulb photo-1

US$ 100 - 198 MOQ: 10 Pieces

Key Specifications

Get Latest Price

LED Light Source:

Bridgelux chip

Warranty(Years):

Input Voltage(V):

90-295V AC

Contact Supplier Request Quote Chat Now

Zhongshan Xingpu LED Lighting Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source Bridgelux chip

Warranty(Years) 3

Input Voltage(V) 90-295V AC

Lamp Power(W) 100

Lamp Luminous Flux(lm) >12500

Lamp Luminous Efficiency(lm/w) 130

Color Temperature(CCT) Other, WW/PW/CW

Working Temperature(℃) -20, 45

Working Lifetime(Hour) 50000

Lamp Body Material Aluminum Alloy

IP Rating IP33

Certification CE, UL

Place of Origin Guangdong, China

Brand Name XINGPU

Model Number XP-HBBZ-100W

Specifications

Bridgelux led 100w led high bay light
1.Light source: Bridgelux 45mil 130lm/W
2.Drive: Taiwan Meanwell
3.Life span: 50000

Newest! Bridgelux led 100w led high bay lighting

100W led high bay light Main Parameters:

Input Voltage		AC90V-295V
Current Frequency		50HZ-60HZ
LED Light Source		Bridgelux led 45mil 130LM/W
LED Qty		100 pcs
LED Power		100W
Total System Power		110 W
Led Luminous Efficiency		120-130lm /W
Led Initial Luminous Flux		>12500 Lm
Illuminance Uniformity		>0.8
Color Temperature		4000K-7000K Can be customized
Color Rendering Index		>78
Light Distribution		symmetric /circle spread
Illuminance Design		LED+Reflector
LED Junction Temperature		≤60°C (@ Ta=30°C)
Working Temperature		-25°C ~ 45°C
Storage Temperature		-25°C ~ +65°C(Best 25°C)
IP Rating		IP33
Net weight		4.85 Kg
Life-span		>50000H
Power Cord		triple shield wire
Connecting Wire		L Live
		N Neutral
		G Earth
Certificate		CE ; RoHS; UL (Power supply only)
Light Fixture Color		White / Black

Features & advantages:
1. Beam Angle: 160 degree
2. Replace the HQI light 200W.
3. 80% more energy saving compared with conventional street light, CFL, Incandescent light.
4. Estimated lifespan: >50, 000 hours
5. Pure white color/Warm white color, high CRI(>80) with great directionality
6. Fast turn on, no warm-up or cold start problems
7. Solve 4 difficulties for LED packaging, heat sinking, operational lifespan, luminous efficiency
8. Special surface design with arc, make sure the radiation diameter on the ground is accord with the standards for size.

Product Application:

Widely used in the lighting of governmen project,sports venues,Basketball court,University library, Meeting hall, Dining room,warehouse,
Business area, airport, metro station, flyover, signboard, gymnasium, landmark and so on.

Related Products:

LEDs are environmentally friendly and healty

conventional energy lamps:

Contain mercury and cadmium.
Emit radiation.
Contain Carcinogens
Cause proven health problems such as dizziness, headaches.
They are destroyed when voltage drops.

Advantage of Leds

LED lamps VERSUS conventional energy lamps
LEDs are absolutely ecological and environmentally friendly as the don’t emit CO2 Carbon Dioxide
They achieve better performance with a reduction in lighting power consumption up to 95%!
No need to change your lighting devices when you change to LED lamps.
The life of the led lamp reaches 50,000 hours. So the cost of constant change and, in general, maintenance drops to zero!
LEDs significantly increase the efficiency of air conditioning in your room, as the led lights do not emit heat.
The led lights are applicable to houses, gardens, swimming pools, cars, the engines, vessels, ships, offices, factories, hotels, roads and generally where there is lighting.
There are more than 1000 kinds of led lamps at your disposal.
They emit far less heat
If you put your hand near the LED lamp when lit, you will sea that you are not going to burn yourself as you would, with an incandescent bulb.
The heat produced by a LED lamp is essentially lost.
The incandescent bulb converts electrical energy to a large extent, to heat rather than light.
Giving power of 5W to an array of LED, we can achieve illumination equivalent to a standard bulb of 60W.
Since they emit no heat, they effectively help the performance of air conditioners.
They “live” longer
LED lighting doesn’t rely on glowing filament (such as common lamps) but on the electron jump (from the cathode to the rise of the LED), and – therefore- the LED lifetime exceeds 50.000 hours.
