2015 New 1 Ton TCM 870 Wheel Loader Parts
1. Our ZL10F wheel loader has fully hydraulic steering system, power shift transmission, easier operation and easier maintenance
2. Our machine has Euro iii engine (Chinese famous brand engine, EPA engine and Japanese imported engine is optional)
3. Comfortable operation environment, air conditioner, back camera is optional
4. Higher dumping and longer arm of wheel loader could be customized
5. We could customize the painting of wheel loader as per request of clients
6.Multifunctional Wheel Loader, the machinery is of high quality and competitive price
| Item | Specification | |
| Rated Load | kg | 1000 |
| Total weight | kg | 2700 |
| Rated Bucket Capacity | m3 | 0.4 |
| Max.Gradeability | ° | 30 |
| Dumping Height | mm | 2700 |
| Overall Dimemsions | mm | 4800*1600*2470 |
| Min.Turning Radius | mm | 3900 |
| Engine Model | changchai L28 | |
| Type | In-line,Water-colled,Four-stroke | |
| Direct injection, four- cylinder | ||
| Rated Power | kw | 20 |
| Rated Speed | rpm | 2200 |
| Gear box | countershaft powershift gearbox | |
| Torque converter | stick shift | |
| Gear Shift | 4F2R | |
| Max.Speed | km/h | 25 |
| Model of Axle | Isuzu Axle | |
| Wheel Base | mm | 1950 |
| Tire | 825-16 | |
| Hydraulic System Pressure | mpa | 16 |
| Rising time | s | ≤ 4.5 |
| Total Cycle Time | s | ≤ 9.0 |
| Function Of Leveling Automatically | Yes | |
| Service Brake | Hydraulic,Expansion-shoe Brake on 4 wheels | |
| Parking Brake | Drum-Type Shoe Brake |
ZL10F wheel loader adopts famouse brand engine which can gurantee the
good performance and high quality.Utilizing baking finish craft, which can improve the surface finish and avoid the problem of peeling off, crack,bubble
of paint.We own professional design team so that we can accept customized
order as per your request.
Our mini wheel loader is multifunctional; we offer many optional attachments which could be used in different fields.
Auger, Drum folder, Grapple forks, Barrel/block clamp, Grapple bucket, 4 in 1 Bucket, Snow Blade and so on.
What is ZL10F's warranty?
- The warranty period of the main machinary is one year; enough free easily damaged parts will be given to you along with the machinery!
What is ZL10F's MOQ?
- 1 set.
- It is optional, any color and any pattern!
| Items | ZL10F | ZL15F | ZL16F | ZL18F |
| Rated Load(ton) | 1 | 1.5 | 1.6 | 1.8 |
| Total weight(kg) | 2700 | 3300 | 3600 | 4800 |
| Rated BucketCapacity(m3) | 0.4 | 0.6 | 0.8 | 1 |
| Max.Gradeability | 30° | 30° | 30° | 30° |
| Dumping Height(mm) | 2700 | 2700 | 3200 | 3200 |
| Overall Dimemsions(mm) | 4800*1600*2470 | 5000*1610*2710 | 5300*1770*2750 | 5700*2020*2800 |
| Min.Turning Radius(mm) | 3900 | 4300 | 4300 | 4600 |
| Items | ZL20F | ZL28F | ZL30F | ZL36F |
| Rated Load(ton) | 2 | 2.5 | 2.8 | 3 |
| Total weight(kg) | 5200 | 5500 | 6800 | 9700 |
| Rated BucketCapacity(m3) | 1.1 | 1.2 | 1.5 | 1.8 |
| Max.Gradeability | 30° | 30° | 30° | 30° |
| Dumping Height(mm) | 3200 | 3200 | 3500 | 3200 |
| Overall Dimemsions(mm) | 5800*2170*2880 | 5800*2170*2880 | 6400*2180*2900 | 7500*2430*3120 |
| Min.Turning Radius(mm) | 4600 | 4600 | 4800 | 5800 |
