China 850kg Mini Avant Skid Loader 4x4 Compact Tractor With Loader
Product features:
1. Small Size, convenience transporting by pick-up, easy operating in narrow place.
2. 30 kinds of attachments
3. With Hyundai or Perkins engine as option
4. Easy changing attachments with quick hitch
5. RoPS/ FoPS Tilting Cab, easy maintenance.
The design is humanized:
1.Handling room provides exceptional working comfort with excellent visibility, enhanced fingertip control and optimum instrumentation;
2.Automatic drawing- back safety belt, when rising, the safety lock lever is able to lock the driving system and controlling handles quickly to make a stopping brake, prevent operator leave the seat accidentally;
3.Operating instrument panel is simple and easy to understand, avoiding mistakes;
4.High comfort, shock-absorbing seat, full closed and low noise handling room air-conditional;
5.Simple operation, easy to learn;
6.Humanization designed, instrument panel provides operating, checking, supervisory controlling function.
| Specifications | JC60G |
| Operating weight(kg) | 3240 |
| Rated operating capacity(kg) | 850 |
| Tipping load(kg) | 1700 |
| Bucket capacity(m3) | 0.45-0.5 |
| Max. travel speed(km/h) | 12 |
| Hydraulic pump flow(L/min) | 75 |
| Fuel tank capacity(L) | 90 |
| Tires | 12/16.5NHS |
| Overall dimensions(mm) | 3490×1820×2150 |
| Dimensions | |
| Height at maximum extension(mm) | 4000 |
| Height to bucket hinge pin(mm) | 3100 |
| Width with bucket(mm) | 1830 |
| Track width(mm) | 1500 |
| Wheelbase(mm) | 1085 |
| Ground clearance(mm) | 200 |
| Dump angle | 30° |
| Dumping height(mm) | 2400 |
| Rollback at ground | 26° |
| Angle of departure | 20° |
| Engine | |
| Maker/Model | Xinchai 498 |
| Net power | 61.2hp/2500rpm |
| Type | 4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine |
| Displacement(L) | 3.2 |
| Standard | Deluxe enclosed operator cab |
| Hand control system(Mechanical type) | |
| Standard bucket | |
| Auxiliary hydraulic couplers | |
| Optional | Preheat starting assist system for extreme cold weather |
| Cab fitted with a heater as standard | |
| Air conditioner | |
| 2-speed transmission system | |
| Attachments | Backhoe,Breaker,Angle |
| blade,Auger,Sweeper,Pallet | |
| fork,Combinition bucket | |
| ,Mower, Asphalt cutter, and More | |
What's JC60G's MOQ?
- 1 set.
What's JC60G's Engine?
- Optional Perkins,Cummins,Deutz.
Can I visit the factory?
- Of course, you will be warmly welcomed!
Qingdao Brilliant Industry & Trade Co., Ltd.
With 20 years experience in the field of engineering industry also under the support by XCMG which is the No. 1 Chinese construction machinery manufacturer, our products has been well recognized by the customers all around the world as the symbol of reliable performance, competitive price, advanced technology and sincere services.
Our Well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfactions, we could also offer OEM services.
SGS Serial NO. | QIP-ASI145346 |
Audit Date | 2-Jul-14 |
Company Name | Qingdao Brilliant Industry & Trade Co., Ltd. |
Business Type | Manufacturer |
Year of Establishment | Mar 14,2014 |
Registered Capital | 83468.27 USD |
Products | Excavator, Wheel Loader, Bulldozer, Forklift and so on |
Number of Employees | 5~10 |
Main Markets | Africa, Asia,Europe,South America |
Sales Personnel: Grace
Tel: 0086-532-80907506
Fax:0086-532-82801885
Skype:brilliantmachinerygrace
Any comment&question,please contact with us freely!
We will try our best to meet your request!
Thanks for your valuable time!
