Specifications
Overhead design.Lifting Height: 1990mm
Overall Height: 3726mm
Two Post Car Lift RP1111
|
Two Post Car Lift RP1111 Specifications | |
| Lifting Capacity | 3200kg/4000kg |
| Lifting Height | 1900mm |
| Minimum Height | 85mm |
| Lifting Time | 40 to 45s/50s |
| Overall Height | 3726mm |
| Overall Width | 3420mm |
| Width Between Columns | 2820mm |
| Motor Power | 2.2kw |
| Power Supply | 220V/380V/415V |
| Weight | 725kg/760kg |
• Clear floor design makes, operator easy working under beneath the vehicles.
• By two cylinder, plate and wire rope chain balance system, lifting off and landing smooth.
• Hydraulic power unit configuration throttling device, can always adjust the rate of decline.
• Asymmetric column allows wider drive through clearance.
• Manual locked release from one side, more convenient to use.
• Take two stages arm design, a larger adjustment range, for different vehicle chassis.
• Retractable tray with three screw-up design, adjustment range 85-115mm.
• With 24V limit switch.
• Rubber pad door-opening protection.
• Screw type up adjustment adapter. Truck adapters can optional. Standard guard rail Toe protection.
• Limit the arm lock with 360°circumferential teeth, increase tensile strength side, a more stable and reliable.
• Have adopted 115% dynamic and 150% static loading tested.
• CE certificated.
