IEP2100 Series Industrial ONU Rs232 to Hdmi Converter

Name: IEP2100 Series Industrial ONU Rs232 to Hdmi Converter
Brand: GCOM
SKU: 114304697
Availability: InStock

IEP2100 Series Industrial ONU Rs232 to Hdmi Converter thumbnail-1

IEP2100 Series Industrial ONU Rs232 to Hdmi Converter photo-1

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

GCOM

Model Number:

IEP2100-4GT-4RS

Contact Supplier Request Quote Chat Now

GCOM Technologies Co., LTD(Shenzhen)

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name GCOM

Model Number IEP2100-4GT-4RS

IEP2100 Series Industrial ONU rs232 to hdmi converter

rs232 to hdmi converter Specifications:

1. 3000 units Sells per Month

2. 1 pcs MOQ
3. 7 working delivery after received money
4. 1 year warranty

rs232 to hdmi converter Product Overview:

IEP2100 series enhanced industrial ONU is the new generation industrial ONU developed by New Greennet, it mainly covers distribution automation users of intellectual grid network constructurtion to satisfy the requirements with ethernet/RS232/RS485 etc. IEP2100 series support power industry EPON specifications and industrial equipment requirement. It adopts FPGA flexible control with dual PON port design, it provides diverter switch and programmable RS232/RS485 interface. These series provide rich services together with NGBNView software to suit for data communication platform.

rs232 to hdmi converter Product Specification:

Attributes	IEP2100-4GT-4RS	IEP2100-4GT
Switching capacity	7.44Mpps	7.44Mpps
Power supply	Support AC 220V , DC- 48V&12V&24V, internal AC-DC or DC-DC power module,support dual- power input, redundancy power supply	Support AC 220V , DC- 48V&12V&24V, internal AC-DC or DC-DC power module,support dual- power input, redundancy power supply
Power consumption	Full-load≤11W	Full-load≤11W
Power consumption	Idle≤6W	Idle≤6W
Outline dimensions (mm) (WDH)	76mm×122mm×186mm	76mm×122mm×186mm
Weight (in maximum configuration)	≤1.5kg	≤1.5kg
Environmental requirements	Working temperature:-40°C~85°C Storage temperature:-40°C~80°C Relative humidity:10%~90%,no condensing	Working temperature:-40°C~85°C Storage temperature:-40°C~80°C Relative humidity:10%~90%,no condensing

rs232 to hdmi converter Business Features:

Attributes		IEP2100-4GT-4RS/4GT
Passive optical network (PON) accessing features		IEEE 802.3ah EPON standard
		GEPON Intercommunication standard for China Telecom/China Unicom
		20Km transmission distance for single optical fiber
		128Bits triple churning encryption for up-down link
		Standard and extensive OAM management
		ONU software batch/ timely/real-time updating
		Luminous power of PON port can accept luminous power detection
L2 features	MAC	1K MAC address
	VLAN	4K VLAN entries
		Port-based VLAN
		Port-isolation in the same VLAN
	Spanning tree protocol	Loop detecting
	Port	Bandwidth control
	Port	Port mirroring
Security features	User’s security	MAC address binds to port and port MAC address filtration
	Device security	Anti-DOS attack(such as ARP,Synflood, Smurf, ICMP attack), ARP detection, worm and Msblaster worm attack
	Network security	Port broadcast/multicast suppression
	QoS	Port-based super queue scheduler and self-defined flow. Each port/ flow supports 4 priority queues and scheduler of FIFS (First In First Serve), SP (Strict Priority) and WRR (Weighted Round Robin).


	Multicast	IGMPv1/v2 Snooping
	Multicast	Cross-VLAN multicast
	Link protection	Static link aggregation(recovery time≤10ms)
	Device protection	4Kv+ lightning protection for port
	Device protection	2Kv+surge protection for power
Maintenance	Network maintenance	WEB-based transceiving statistics for port
	Device management	GEPON OAM/CTC OAM/SNMP configuration management
	Device management	Input/output configuration files for batch configuring
