Help CenterBelt Weighfeeder Controller
Related Products
1.Suitable for Ration Belt Weighfeeder with Ration Flow Feeding & Ration Weight Batch Control
2.EMC design with high anti-jamming capability suitable for industrial environment
3.16 bits LED for digit display screen for english character display
4. English Keypad for Menu&Shortcut mode operation with key tone
5. High-precision conversion technology and broad-range speed pulse input circuit
6. Max Connection Quantity 8 Loadcells (350Ω)
7. Auto-locking Key-locking Key-unlocking Digital Setting&Calibration and I/O Testing functions available
8.Auto Zero Tracking Speed Calibration and Belt Length Calibration functions available
9. One optional Flow Setpoint analog signal input [AI 4~20mA]
10. Max3 definable Flow/Control Current /… analog signal outputs [AO 4~20mA]
11 .Quick and steady PID for ration feeding control available
12. 3 Definable normally open switch inputs [DI] and 4 definable normally open relay or transistor switch outputs [DO]
13. The feeder and belt weigher can be started and stopped by DI&DO signals
14.1Totalized Weight High-speed Pulse output [PO]
15. 2 Optional communication ports for linking to IPC/PLC remote display&operation terminal serial printer and wireless module
16.Support industry configuration software eg iFix
17.Weight Records per shift/day/month of a year can be queried and printed
18.With the multitasking mode the weighing&control process will not be interrupted by parameter setting and the other operations
