Help CenterBelt Weigher Controller
Related Products
Specifications
Suitable for belt weigher.
Technical Specifications
Power Supply
Operating Voltage: AC220V±15%.
Operating Frequency: 50/60Hz.
Max. Power: 10W.
Display
160×32 dots LCD display screen with yellow-green background for Chinese/English character display.
Keypad
16 keys for Menu&Shortcut mode operation with key tone.
Auto-locking, Key-locking,Key-unlocking and Digital Setting&Calibration functions available.
Loadcell Signal Input Interface (SENSOR/LOADCELL)
1 Weighing Signal Input: 0~25mV.
Excitation Voltage Output: DC10V.
Max. Connection Quantity: 8 Loadcells (350Ω).
Weighing Accuracy
24-bit Σ-ADC.
Sampling Frequency: 200Hz.
Zero Drift: ±0.1μV/°C RTI (Relative to Input).
Gain Drift: ±5ppm/°C.
Non-linearity: 0.005%FS.
Speed Sensor Signal Input Interface (SENSOR/SPEED)
1 Speed Pulse Input Signal.
Frequency Range: 0.5~3000Hz.
Output Voltage: DC5~12V (adjustable); Max. Current: 100mA.
Flow Analog Signal Output Interface (AO FROM COM1)
Optional AO [4~20mA] module for Flow signal output.
COM1 port will be occupied.
Non-linearity: 0.05%FS.
Digital Communication Interface (COM1/2)
COM1 Optional: RS232/RS485/RS422/Profibus-DP/CANBUS/Ethernet modules.
COM2: RS232.
Connectable: IPC/PLC, Remote Display&Operation Terminal, Serial Printer and Wireless Module.
Power Supply Output: DC5V, 100mA.
Report Print
Weight Records per shift/day/month of a year can be queried and printed.
Outline Dimension: 170 × 91 × 184 mm (W×H×D).
Cut Dimension: 151 × 76 mm (W×H).
Weight: Approx. 1.3kg.
Temperature and Humidity
Service Temperature: -20°C to +40°C.
Storage Temperature: -30°C to +60°C.
Relative Humidity: Max. 85%RH.
IP Grade: IP50.
Belt Weighing System
