Specifications
pneumatic fender1.high bursting strength
2.diametre:0.5-3.5m
3.strict quality test
High-quality floating pneumatic rubber fender:
The floating pneumatic rubber fender is made of synthetic-corrd-reinforced rubber sheet with compressed air inside to enable it to float on the water and work as a shock absorber between two ships, or between ships and berthing structures when they come alongside each other on the water.
Features:
1. easy and fast to install
2. massive energy absorption , low unit surface pressure
3. equipped with chains and tire net as cover,providing furthur protection
4. chains are galvanized for greater corrosion resistance
5. low cost of maintenance
6. widely used: :large tankers, LPG vessels, ocean platforms, large docks, harbor and wharves
Quality test:
Parallel compression test
Angular compression test
Durability test
Air-leakage test
Specifications:
Initial Pressure |
50kPa = 0.5kgf/cm2 = 7.1psi |
80kPa = 0.8kgf/cm2 = 11.4psi |
|||
|
Size mm(D)×mm(L) |
Energy (kNm) |
Reaction (kN) |
Energy (kNm) |
Reaction (kN) |
|
500 x 1000 |
6 |
64 |
8 |
85 |
|
600 x 1000 |
8 |
74 |
11 |
98 |
|
700 x 1500 |
17 |
137 |
24 |
180 |
|
1000 x 1500 |
32 |
182 |
45 |
239 |
|
1000 x 2000 |
45 |
257 |
63 |
338 |
|
1200 x 2000 |
63 |
297 |
88 |
390 |
|
1350 x 2500 |
102 |
427 |
142 |
561 |
|
1500 x 3000 |
153 |
579 |
214 |
761 |
|
1700 x 3000 |
191 |
639 |
267 |
840 |
|
2000 x 3500 |
308 |
675 |
430 |
1150 |
|
2500 x 4000 |
663 |
1381 |
925 |
1815 |
|
2500 x 5500 |
943 |
2019 |
1317 |
2653 |
|
3300 x 4500 |
1175 |
1684 |
1640 |
2476 |
|
3300 x 6500 |
1814 |
3015 |
2532 |
3961 |
|
3300 x 10600 |
3067 |
5257 |
4281 |
6907 |
|
4500 x 9000 |
4752 |
5747 |
6633 |
7551 |
|
4500 x 12000 |
6473 |
7984 |
9037 |
10490 |
|
