Help CenterPE Pipe Floater
Related Products
Specifications
PE pipe floater1.light weight,good toughness
nvenient to install and demount
3.reuse is available
4.anti-wave,anti-agin
PE Pipe Floater:
The cover material is density polyethylene plastic, it can provide great buoyancy.The filled material is Polyurethane foamed plastic .The thickness ranges from 5mm--66mm.
The polyethylene foam float usually cover outside the HDPE pipe and rubber hoses to provide great buoyancy.
Features:
1. gasoline-resistance, diesel oil-resistance
2. light weight,good toughness
2. convenient to install and demount
3. reuse is available
4. anti-wave,anti-aging
Specification:
No. |
Ship Type |
ID of Dredging Pipe |
float |
||
|
(mm) Outer Diameter |
(mm) Inner Diameter |
(mm) Length |
|||
1 |
200m³ |
Ø400- Ø420 |
Ø1300 |
Ø430 |
1020 |
2 |
350 m³ |
Ø550- Ø560 |
Ø1300 |
Ø586 |
1200 |
3 |
1600 Beaver 1600 |
Ø500 |
Ø1300 |
Ø526 |
1120 |
4 |
3800 Beaver 3800 |
Ø650 |
Ø1460 |
Ø670 |
1200 |
5 |
4600 Beaver 4600 |
Ø700 |
Ø1500 |
Ø720 |
1300 |
6 |
|
Ø800 |
|
|
|
|
Remarks: 1.Two pairs of floats form one group, two pieces form one pair. 2. One group of float can support dredging hose in six hose in six meters length. | |||||
Performace:
Item |
Case Function Target |
Item |
Internal Function Target |
Tensile Strength |
12Mpa±2 |
Water Absorption |
0.16-0.2g/100c m³ |
Elongation @ Breaking |
10.1% |
Breaking Strength |
0.8-1.0kg/100c m³ |
Lash Intensity |
31.4KJ/ m ² |
Elongation @ Breaking |
4-6% |
Bending Strength |
15.7 Mpa |
Compressive Strength |
1.0-2.4kg/100c m³ |
|
|
Heat-resistance |
-50°C - +60°C |
