2014 Pe/pvc Water Conduit

2014 Pe/pvc Water Conduit photo-1
US$ 0.2 - 1 MOQ: 3000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
XINFA
Model Number:
25mm-300mm
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name XINFA
Model Number 25mm-300mm
Material PVC
Specification 1''-12''
Length 50m , 100m,20-100m /roll
Thickness 1mm -2.2mm
Standard TS

Specifications

1. PVC flat Water Hose
2. Made of qualify plastic material
3. Ideal for water convey in farmland,construction site

PVC  Water Hose

Features:

· 1. very light weight and highly flexible

· 2. resistance to weathering and ozone

· 3. small coil diameter

· 4. excellent layer adhesion compared conventionaleasy use & storage

· 5. service temperature: -10 up to 60 (14 up to 140) based on water

specifications of PVC water hose

· 1. agriculture and industry

· 2. commercial and engineering

· 3. supply line for drip irrigation

lining and cover

· 1. special high grade formulated PVC compound

· 2. much better adhesion level compared to conventional

· 3. inside: very smooth for minimum friction loss

· 4. outside: smooth for good flexibility

construction

Textile reinforcement

· 1. high tenacity , polyester yarn , special construction for low elongation.

· 2. totally embedded  in the PVC compound , excellent protected against mechanical damage





Size

I.D 2Bar 3Bar 4Bar 6Bar 8Bar
inch (mm) kg/m kg/m kg/m kg/m kg/m
1" 25.4±1.0 0.12 0.15 0.18 0.20 0.23
1-1/4" 31.8±1.0 0.15 0.18 0.23 0.25 0.28
1-1/2" 38.1±1.2 0.18 0.23 0.28 0.30 0.35
2" 50.3±1.5 0.23 0.30 0.35 0.37 0.50
2-1/2" 63.5±1.5 0.30 0.38 0.50 0.55 0.60
3" 76.2±2.0 0.36 0.45 0.60 0.65 0.85
4" 101.6±2.0 0.50 0.65 0.85 0.95 1.10
5" 121.0±2.5 0.65 0.85 1.00 1.20 1.35
6" 152.4±2.5 0.85 1.00 1.35 1.50 1.65
8" 203.2±2.8 1.50 1.75 1.90 2.20 2.30
10" 254.1±3.0 2.50 2.65 2.80 3.20
12" 304.8±4.0 3.00 3.20 3.50







 If you have any request please contact with us at anytime.

 2014 pe/pvc water conduit2014 pe/pvc water conduit2014 pe/pvc water conduit2014 pe/pvc water conduit2014 pe/pvc water conduit2014 pe/pvc water conduit
