Specifications
.Output off function.Constant voltage and constant current
.Aluminium alloy panel
.DC power supply
M30-SP303E - DC POWER SUPPLY
Features
.Output off function
.Constant voltage and constant current
.Aluminium alloy panel
.Series and parallel tracking function(M30-TP Series)
.One adjustable output & two fixed outputs(M30-YP Series)
.Line Regulation: CV1x10-4+3mV CC2x10-3+3mA
Fixed output 10mV (M30-TP Series)
Fixed output 1% (M30-YP Series)
.Load Regulation: CV1X10-4+4mV CC2X10-3+5mA
Fixed output 10mV (M30-TP Series)
Fixed output 1% (M30-YP Series)
.Ripple & Noise: CV1mVrms CC3mA rms
Fixed output 10mV(M30-TP & YP Series)
.Fixed Output Accurary: 2.5% (M30-TP & YP Series)
.Display Accuracy: Voltmeter±(0.2%Rdg+2digits)
Ampmeter±(1.0%Rdg+2digits)
.Input Voltage: 110~127VAC±10%, 220~240VAC±10%
Switchable
| Model | Output 1 | Output 2 | Output 3 | Dimensions(LxWxD) | Weight (kg) |
|---|---|---|---|---|---|
| M30-YP202E |
0~20V 0~2A |
12V 500mA |
5V 500mA |
170x160x250mm | 6 |
| M30-YP303E |
0~30V 0~3A |
12V 500mA |
5V 500mA |
170x160x250mm | 6 |
| M30-YP305E |
0~30V 0~5A |
12V 500mA |
5V 500mA |
170x160x250mm | 7 |
| Model | Voltage | Current | Dimensions(LxWxD) | Weight (kg) |
|---|---|---|---|---|
| M30-TP202E |
0~20Vx2 5V |
0~2Ax2 2A |
260x160x340mm | 10 |
| M30-TP303E |
0~30Vx2 5V |
0~3Ax2 3V |
260x160x340mm | 10 |
| M30-TP305E |
0~30Vx2 5V |
0~5Ax2 3V |
260x160x340mm | 10 |
| Model | Voltage | Current | Dimensions(LxWxD) | Weight (kg) |
|---|---|---|---|---|
| M30-SP202E | 0~20V | 0~3A | 132x160x270mm | 5 |
| M30-SP303E | 0~30V |
0~3A |
132x160x270mm | 5 |
| M30-SP305E | 0~30V |
0~5A |
132x160x270mm | 6 |
