MCP M10-QS303 Alimentation 0-30V 3A/dc Stabilized Power Supply/0-30vdc Power Supply / 30vdc 3 Amp Power Supply
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
MCP
Model Number:
M10-QS303
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
M10-SP703E - Single Output Adjustable DC Power SupplyNegotiableMOQ: 10 Pieces -
MCP M30-TP303E - DC POWER SUPPLYNegotiableMOQ: 10 Pieces
-
M10-MX304 Adjustable DC Power SupplyNegotiableMOQ: 20 Pieces
-
M10-300-10 - 13.8V POWER SUPPLYNegotiableMOQ: 20 Pieces
-
M10-QR305 DC Power Supply/30v 5a Variable dc Power Supply/ac to dc Variable Power SupplyNegotiableMOQ: 10 Pieces
Place of Origin
Shanghai, China
Brand Name
MCP
Model Number
M10-QS303
Output Power
51 - 100W
Output Type
Single
Input Voltage
Other
Features
. 16 hours continuous output with full load
. Constant voltage and constant current
. Low ripple and noise
. CV/CC auto switching
. Aluminum fin cooler
. 3 digits LED display (4 digits LED display is optional)
Specifications
.Line Regulation: CV 1X10-4+3mV CC 2X10-3+3mA
.Load Regulation: CV 1X10-4+4mV CC 2X10-3+5mA
.Ripple & Noise: CV 1mVrms CC 3mA rms
.Display Accuracy: Voltmeter±(0.2%Rdg+2digits)
Ampmeter±(1.0%Rdg+2digits)
.Input Voltage: 110~127VAC±10%, 220~240VAC±10% Switchable
| Model | Voltage | Current | Over voltage protection |
Dimensions(LxWxD) | Weight (kg) |
|---|---|---|---|---|---|
| M10-QS302 | 0~30V | 0~2A | 130x165x320mm | 5 | |
| M10-QS303 | 0~30V |
0~3A |
130x165x320mm | 5 | |
| M10-QS305 | 0~30V | 0~5A | 130x165x320mm | 5 | |
| M10-QS3010 | 0~30V | 0~10A | 250x135x300mm | 9 | |
| M10-QS3020 | 0~30V | 0~20A | 250x135x300mm | 9 | |
| M10-QS603 | 0~60V | 0~3A | 130x165x320mm | 5 | |
| M10-QS605 | 0~60V | 0~5A | 250x135x300mm | 11.5 | |
| M10-QS6010 | 0~60V | 0~10A | 250x135x300mm | 15 | |
| M10-QS1001 | 0~100V | 0~1A | 130x165x320mm | 5.5 | |
| M10-QS1003 | 0~100V | 0~3A | 130x165x320mm | 11.5 | |
| M10-QS1005 | 0~100V | 0~5A | 250x135x300mm | 14 | |
| M10-QS2001 | 0~200V | 0~1A | 250x135x300mm | 7 | |
| M10-QS2003 | 0~200V | 0~3A | 250x135x300mm | 15 | |
| M10-QS3030 | 0~30V | 0~30A | √ | 250x135x460mm | 18 |
| M10-QS6020 | 0~60V | 0~20A | √ | 250x135x460mm | 20 |
| M10-QS2005 | 0~200V | 0~5A | √ | 250x135x460mm | 18 |
