MCP M10-MSS6008 Regulated Switching Power Supply 0- 60V 7.5A

MCP M10-MSS6008 Regulated Switching Power Supply 0- 60V 7.5A thumbnail-1
MCP M10-MSS6008 Regulated Switching Power Supply 0- 60V 7.5A photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
MCP
Model Number:
M10-MSS6008
Contact Supplier Request Quote Chat Now
Shanghai MCP Corp.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name MCP
Model Number M10-MSS6008
Output Power 401 - 500W
Output Type Single
Input Voltage 220V
Output Voltage 60V
Output Frequency 50/60Hz
Output Current 7.5A

M10-MSS6008 SWITCHING POWER SUPPLY 60V 7.5A



Features

. 450W power output

. Constant voltage and constant current

. Temperature control fan and over heat protection





Specifications

Line regulation: CV 6×10-4+3mV CC 2×10-3+3mA
Load regulation: CV 2×10-3+5mV CC 2×10-3+3mA
Ripple & noise: CV 15mVrms CC 15mArms
Display accuracy: Voltmeter±(1.0%Rdg+2digits)    Ammeter ±(1.0%Rdg+2digits)
Input voltage: 110~127VAC±10% 60Hz or 220~240±10% 50Hz

Model Voltage Current Resolution Dimensions(WxHxD) Weight (kg)
M10-MSS3015 0~30V 0~15A 100mV/100mA 105x160x215mm 2.2
M10-MSS6008 0~60V 0~7.5A 100mV/10mA 105x160x215mm
M10-MSS1005 0~100V 0~4.5A 100mV/10mA 105x160x215mm
