18W T8 U shape LED tube light with length of 22.5 inches long
Dimension: T8 561.05x2+152mm
LED's Q'ty:216pcs 2835 LEDs
Payment Term: TT or Paypal
Shipping Term: by express, by air or by sea(up to you)
Delivery Time: 4-7days for sample; 7-14days for bulk
Min order:10pcs
Model No.: TP-T8SMD216U-18W
FOB Port: Shenzhen port
Power:12W 14W 16W 18W
U Shape LED Tube,2ft T8 LED U shape,18W LED U bend
AC85-277V LED U shaped Tube Light,U-Shaped LED Lamp
.
Paramter
| TP-T8SMD108U-12-14W | Product | U bend led | Input Voltage | 85-277VAC | Product size | 572MM±2:185MM±2:30MM±1 | |
| LED | 2835/SMD | Input Frequency | 47-63HZ | Material | 6063 AL+PC | ||
| |
LED chip Q'ty | 108PCS | PF | PF>0.98/110VAC | N.W | 0.38KG | |
| LED chip Lumen | 8-9LM/PCS | PF>0.93/230VAC | Single Packing size(MM) | 585*190*38 | |||
| Color Temperature | WW,NW,CW | PF>0.90/270VAC | G.W | 0.6KG | |||
| Ra | Ra≥72 | Input current | 0.073A/230VAC 0.138A/110VAC | Packing | 10PCS/CTN | ||
| Beam Angle(°) | 120 degree | Power | 12-14W | G.W/cas | 6.2KG | ||
| Luminous Intensity(LM) | 1100-1400lm | Driver | Rubycon Isolated driver | Packing size(mm) | 610*420*230 | ||
| PC cover | Frosted PC/stripe | Base | G13 | Warranty | 3 years | ||
| operating humidity | 20-80% RH no condensation | Operating Temperature | -20--+55℃ |
| TP-T8SMD216U-16-18W | Product | U bend led | Input Voltage | 85-277VAC | Product size | 572MM±2:185MM±2:30MM±1 |
| LED | 2835/SMD | Input Frequency | 47-63HZ | Material | 6063 AL+PC | |
| LED chip Q'ty | 216PCS | PF | PF>0.98/110VAC | N.W | 0.4KG | |
| LED chip Lumen | 8-9LM/PCS | PF>0.93/230VAC | Single Packing size(MM) | 585*190*38 | ||
| |
Color Temperature | WW,NW,CW | PF>0.90/270VAC | G.W | 0.62KG | |
| Ra | Ra≥72 | Input current | 0.084A/230VAC 0.158A/110VAC | Packing | 10PCS | |
| Beam Angle(°) | 120 degree | Power | 16-18W | G.W/cas | :6.3KG | |
| Luminous Intensity(LM) | 1500-1800lm | Driver | Rubycon Isolated driver | Packing size(mm) | 610*420*230 | |
| PC cover | Frosted PC/stripe | Base | G13 | Warranty | 3 years | |
| operating humidity | 20-80% RH no condensation | Operating Temperature | -20--+55℃ |
Advantage:
Features of T8 U-Shaped LED Tube :
a,LED 2835SMD,high brightness,high power efficiency.
b,Material:Al+PC cover,heat sink hold,good haet sink design.
c,12W,14W,16W,18W 4 size to replace the nornal fluorescent tube.
d,Driver build-in,Janpan Rubycon isolated driver 85-277VAC
e,Reasonable price,High quality,Fast Delivery
Aging:
Application
1. Supermarkets, hotels, Restaurants;
2. Exhibition hall, show window, and other home application;
vehicle repair plant ,gas station, coal mine, Diamond mine, construction plantworkshop,warehouse,cement silo.
3. Ideal for the replacement of traditional light.
Other products
Afterservice and remarks
1,Payment : T/T, (Western Union Paypal are welcome)
2.Sample lead time: 1-7days
3.Production lead time: for 100~500pcs1- 7days ;500~1000pcs 7-14days
4.Shipping freight are delivered under your requests
5.Shipping port :shenzhen ,mainland china
6.Discounts are offered based on order quantities
7.Minimum Quantity:30pcs(accepted sample :1-10pcs)
8.Logo: According to your requirement
9.Packaging: 1pc /gift box/white mail order box
10.Shipping: By Express(EMS,DHL,UPS,ARAMEX), By Air or By Sea
Your inquiry will be replied in 24hours.
Welcome to audit to our factory if it's convenient for you ^_^
