Specifications
Hi-IP LED high bay120W
85-265VAC
10000-11000Lm
Special Feature :
1. Quality Waterproof Driver with 5-year warranty(Taiwan Meanwell driver)
A, High EMC,no interfere
B, Power factor>0.95
C, Power Efficiency>90%
D, UL, TUV, PSE compliance
E, Full protection: short circuit , over voltage , over current and over temprature
2. High-performance Original CREE LED( Made in USA ) and perfect wiring design
Even if one led failed, the remaining LEDs will still work.
3, Safety
A, CE, RoHS, PSE, FCC, IP65
B, ATEX approved( Explosion proof )
C, EMC approved ( No interfere )
D, IP66 approved ( Water proof )
E, EN 62471 (Photobiological Safety)
F, 4000V Hi-pot test pass
4,Low Light Loss
The light source is the low light loss and high-bright LED, in which the loss is less than 5% for every 10,000 hours. The aluminum back-side housing performs an excellent heat dissipation, which guarantees a lower junction temperature of the LED, thus slowing down light loss.
5,Environment-Friendly
While working, no ultraviolet light and infrared light radiation. And does not contain any hazardous substance, such as Lead and Mercury.
6,Anti-vibration
Solid-state device. Can withstand Moderate vibrations
7,Warranty Policy
3 years warranty with free collection and delivery
Technical Specification:
Item NO. |
CA-HBXW12-120W |
Power consumption |
120W±10% |
Replacement: |
300-350W HPS |
Working Voltage |
85-265VAC , 50Hz/60Hz |
Color Temperature |
3000-6500K (Warm White Nature white ,Cool White available ) |
LED brand |
Original CREE LED |
Luminous Efficacy |
90Lm/W |
Luminous flux |
10000-11000Lm |
Beam Angle |
60 /120 Degree |
IP Class |
IP66 |
Rated lifetime |
50,000Hrs |
Working Temperature |
-40~+70°C |
Power Efficiency |
>90% |
Power factor |
>0.95 |
Net Weight |
3.5KGS |
Luminous uniformity |
>0.7 |
Lamp size |
250mmX250mmX288/295mm |
Material |
Aluminum |
