Help CenterAluminium Led Lights 18w Led T10 Tube
Related Products
-
Hot Sale 20w External Driver 3528 Led T10sUS$ 32.56 - 35.48MOQ: 1 Piece -
Hot Sale!! Milky Cover Led Tube T10 LightingsUS$ 29.35 - 32.27MOQ: 1 Piece
-
Bright Indoor Using 906mm SMD T10 LED Tube LightNegotiableMOQ: 30 Pieces
-
2012 New Products T10 Led Tube Light Eye-protecting Led TubeUS$ 20.84 - 22.56MOQ: 1 Piece
-
T10 Led Tube Light Led Tube 10W Energy SavingUS$ 20.84 - 22.56MOQ: 1 Piece
Specifications
18W T10 led tube light (CE and RoHs)1.Input voltage:85-277V
2.more than 50000hours
3.CE and RHOS certificate
4.3years
1. Introduction of LED Tube Light
LED tube of Ledboss is a super bright, lowest attenuation of brightness, extraordinary energy saving, tremendous long life as light source, possesses low power consumption, high brightness, long life, Shockproof and vibration-proof, low thermal output with No infrared and UV, No harm to human, low maintenance cost, easy installation etc. The lumen of single LED nearly reaches to 7 LM and color rendering index is above 85%.
2. Features of LED Tube Light
1) Constant current cover,ultra-low power consumption,photoelectric efficiency can reach 90%. It can save 60% energy than traditional T8 Fluorescent Tube and 90% energy than traditional incandescent lamp with same lighting effects.Furthermore.
2) No UV,infrared radiation ,mercury and other harmful things,low heat dissipation can reduce thermal pollution to the air.
3) Long Lifespan:Supass 50000 hours,10 times longer than traditional one.
4) Sup erhigh lighting effect:adopt superhigh brightness LED.
3.Application
1) Supermarkets, Factory production line,warehouse.
2) Hospital,schools,office buildings, Refrigeration houses and freezers.
3) Metro,tunnel,square,parking lots and so on.
4.Technical specifications
Technical specifications of 18W T8 LED fluorescent tube | |
Introduction | |
Base (standard designation) |
G13 |
Shell material |
Aluminum + Plastic(half aluminum,half plastic) |
Plastic cover version |
Clear/ Wave/ Frosted |
Mercury-free |
Yes |
Recycling |
Yes |
Certificates |
CE,RoHS,UL,PSE |
Main electrical data | |
Rated wattage(Walt) |
18 |
Total wattage/power(Walt) |
18±1W |
Luminous Flux |
1980lm |
Input Voltage (Nominal voltage) |
AC85-277V |
Operating frequency |
50~60 Hz |
Power factor(PF) |
>85% |
Polarity |
Bipolar Protection |
LED Drive |
constant-current drive |
Light Source |
0.06W SMD3528 LED |
LED lamps quantity |
330 |
Light Technical Data | |
Rated luminous flux (LM/W) |
85-180 |
Beam Angle |
60/120° |
Rated color rendering index (Ra) |
≥75 |
Rated color temperature (k) |
2800-3500K/4000-4500K/5000-6500K/6500-7500K |
Light color |
Warm white/Netural(Nature)white/Pure white/Cool white |
Operating temperature(Celsius degree) |
-20~+85 Degrees Celsius |
Storage temperature(Celsius degree) |
-30~+45 Degrees Celsius |
Operation Humidity(RH) |
10%~90% |
