LED Light Source Epistar SMD2835 LED
Warranty(Years) 3
Input Voltage(V) 85-277VAC
Lamp Power(W) 30
Lamp Luminous Flux(lm) 3300lm
Lamp Luminous Efficiency(lm/w) 110
Color Temperature(CCT) Other, 2700~6500K
Working Temperature(℃) -25, 50
Working Lifetime(Hour) 50000
Lamp Body Material Other, Aluminum+PC
IP Rating IP33
Certification CE, EMC, FCC, LVD, PSE
Place of Origin Guangdong, China
Brand Name Toplight
Model Number Other, TP-T10SMD616DS-30W

2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp!

2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp



Product Description

5ft Double sides LED Tube T10 Specifications:

Model No.
 TP-T10SMD616DS-30W

Electrical Parameters

Rated Power
30W
Rated voltage
 AC 85~277V
Rated frequency 50-60HZ
Power Factor >0.90
Driver Type
 Built-in Isolated driver with Rubycon capacitor
Replacement Type
 Replace traditional lamp with inductive or electronic ballast
Power supply
high-performance frequency constant current power supply

Optical Parameters

LED Chip Brand Taiwan Epistar Chip
LED chip quantity 2835SMD 616pcs
Viewing angle
 180°*2=360°
Color temperature   2700~6500K
Luminous Flux   3300~3600lm
Light Efficiency
 110~120lm/w
CRI
 70/80Ra

Structure Info

Shine Side
 Two sides
Lamp holder
G13/R17D/FA8
Specific Function
End cap rotatable
Tube Material
PC cover+6063 aluminum
Product Size
L1512*Tube Dia31.8mm
Heat sink material
 6063 aluminum
PC Cover Kind
Milky/Clear
Packaging Info
Inner box size Diameter 37.5*Length 1530mm
External carton size

L1635*W250*H250mm
Product N.W. 0.69KG/pc
Product G.W. 0.91KG/pc
Packaging quantity 30pcs/carton
Carton weight 29.25KG/carton
Other Parameters
Operating humidity
20-80%  RH no condensation
Temperature Environment
 -25℃~+50℃
Tube surface temperature
 Below 45 ℃
Life time
50000 hours
Certifications
 CE(EMC,LVD)/RoHS/PSE/FCC
Warranty 3 years





Double sided T10 LED tube Advantages:

1.LED Chip: Taiwan Epistar Chip SMD2835,pure gold wire,616leds/30w/pc,lumen>3300lm.

2.Independent Design,and use aluminum with toothing shape to increase heat sink area.

3.Imported PC cover and RUBYCON capacitor from Japanese,which is the highest level.

4.Professional design for billboard lights, Two sides shine equal to 2 pcs led lights.

5.Don't need lamp support any more, and be directly installed by our parts.

6.Under long time working, the temperature rise isn't  more than 5 ℃ .




Double-sided lighting led tube Pictures Show:

2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp



2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp



2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp



2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp



2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp



2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp



2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp





New type LED tube double sided lighting T10 Size:

2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp

T10 LED Tube diameter: 31.8mm ;  the length:60cm/90cm/120cm/150cm/180cm/240cm.





T10 LED Tube double-sided lighting Replacement Instruction:

The single side supply replacement:

2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp





360degree Double-sided T10 LED Tube Application:

2015 Hot selling 5ft T10 LED Tube to Replace Old Type Flourescent Lamp

Mainly apply to indoor or outdoor billboard lighting, shopping mall lighting, advertising box,etc.
