T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face

T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face thumbnail-1
T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face thumbnail-2
T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face thumbnail-3
T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face thumbnail-4
T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face thumbnail-5
T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face thumbnail-6
T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face photo-1
T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face photo-2
T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face photo-3
T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face photo-4
T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face photo-5
T10 Model 360 Degree Smd2835 G13 R17d Fa8 Led Tube Double Face photo-6
US$ 14 - 18 MOQ: 2 Pieces
Key Specifications
Get Latest Price
LED Light Source:
Epistar 2835
Warranty(Years):
3
Input Voltage(V):
85-265VAC
Contact Supplier Request Quote Chat Now
Shenzhen Toplight Lighting Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source Epistar 2835
Warranty(Years) 3
Input Voltage(V) 85-265VAC
Lamp Power(W) 26
Lamp Luminous Flux(lm) 2400-2700lm
Lamp Luminous Efficiency(lm/w) 100
Color Temperature(CCT) Other, Cool White, Natural White, Warm White
Working Temperature(℃) -20, 40
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating Other, IP42
Certification CE, EMC, FCC, LVD, PSE
Place of Origin Guangdong, China
Brand Name Toplight
Model Number T10

T10 model 360 degree smd2835 g13 r17d fa8 led tube double face

Product Description

LED Double Shine T10 Tube Light: G13 base, can be installed on T8/T10/T12 fixture, 2sides brightness, clear/frosted PC



Electrical parameter

Tube Length

(mm)

Model No.

LED Quantity

(pcs)

Luminous Flux

(lm)

Socket

602mm

TP-T10SMD216DS-13W

216LEDs

1130-1358lm

G13/R17D/FA8

TP-T10SMD288DS-16W

288LEDs

1600-1710lm

G13/R17D/FA8

906mm

TP-T10SMD378DS-20W

378LEDs

1920-2120lm

G13/R17D/FA8

1212mm

TP-T10SMD288DS-18W

288LEDs

1620-1780lm

G13/R17D/FA8

TP-T10SMD432DS-24W

432LEDs

2300-2408lm

G13/R17D/FA8

TP-T10SMD552DS-36W

552LEDs

3200-3400lm

G13/R17D/FA8

1512mm

TP-T10SMD432DS-24W

432LEDs

2300-2410lm

G13/R17D/FA8

TP-T10SMD600DS-40W

600LEDs

3800-4018lm

G13/R17D/FA8

2382mm

TP-T10SMD576DS-38W

576LEDs

3110-3600lm

G13/R17D/FA8

TP-T10SMD864DS-60W

864LEDs

5800-5942lm

G13/R17D/FA8

Basic parameter

PC and color temperature

Power

13W,16W,20W,18W,24W,36W,24W,40W,38W,60W

Cloror temoerature

Warm White

(2700-3500K)

LED Quantity

216LEDs,288LEDs,378LEDs,288LEDs,

432LEDs,552LEDs,432LEDs,600LEDs,

576LEDs,864LEDs

Natural White

(5000-6000K)

Input voltage

100-245VAC

 Cool White

(6500-7000K)

Beam Angle

180degree

PC

Clear PC

Power Factor

>0.85

Power Efficiency

>92%

Frosted PC



Material

AL+PC

Lifespan

50000

 Tube surface temperature Below 45 ℃

Certifications

CE(EMC,LVD)/RoHS/PSE

 Warranty 3 years
T10 led double shine lights  Features &Advantages
  • Work directly on rated voltage, No RF interference
  • CE, and ROHS  PSE approval, 50,000hours lifespan, Mainenance free
  • REMOVE both ballast and starter before substitution of traditionalT8/T10
  • Quiet without noise or flicker
  • Own open model makes sure emitting uniform light
  • with good aluminum lamp housing, with excellent heat dissipation
  • Unique designed: Excellent heat dissipation
  • Particular inner design: makes the tubes with no shadow area
  • Elegant plastics end cap, nice and safe for human
  • Taiwan chip SMD3528;super brightness and low degradation make sure of long life span of LEDs
  • Ultra quality drivers and other electronical components extend the life of LED
T10 led double shine lights show
T10 model 360 degree smd2835 g13 r17d fa8 led tube double faceT10 model 360 degree smd2835 g13 r17d fa8 led tube double faceT10 model 360 degree smd2835 g13 r17d fa8 led tube double face
35W T10 LED double shine tube light test report
T10 model 360 degree smd2835 g13 r17d fa8 led tube double face
T10 LED double shine tube light Type
T10 model 360 degree smd2835 g13 r17d fa8 led tube double faceT10 model 360 degree smd2835 g13 r17d fa8 led tube double face
T10 LED double shine tube light installation
T10 model 360 degree smd2835 g13 r17d fa8 led tube double faceT10 model 360 degree smd2835 g13 r17d fa8 led tube double face
T10 led double shine tube lights atention

This mold has biggest advantage when compared with old public mold

  1. The heat radiating area of aluminum tube(sawtooth) is nearly  twice as large as old type.,so that excellent heat dissipation;Because the power of he double sides shine tube is bigger than the normal light tube ,firstly the heat dissipation must be solved,and is the inevitable requirement of product stability
  2. Lamp cap can be fixed with screw,to solve the glue fixed shortcomings,high quality assurance,good product consistency
  3. Buil-in certification has enough space with isolation power supply,appropriate space area,it is convenient  to installation of old aluminum isolated power,product is safe and reliable
  4. Because this product aluminnum tube heat dissipation area increased ,besides good heat dissipation,the product weight  also is increased ,Even 2.4m tubes,it is not easy to deformation and middle bending decrease obviously
The product's sceond bright spot:there are optional mounting hardware by independent design,in the absence of mounting bracket you can choose the design of hardware for installation,quick and convenient,cost savings.Install a matching sparately,with the installation instructions!
More SMD2835 LED tube T10 double shine tube lights
T10 model 360 degree smd2835 g13 r17d fa8 led tube double faceT10 model 360 degree smd2835 g13 r17d fa8 led tube double face
Packaging & Shipping
T10 double sides shine led tube lights packing
  • General case we use kraff paper tube packaging
  • Customised design is welcome
  • Printing your company logo as your request,flexo or offset printing is available
T10 double sides shine led tube lights shipping
  • Small order can be acceptted
  • Offerring the fast delivery date,3 to5 workdays
T10 model 360 degree smd2835 g13 r17d fa8 led tube double face
Our Services
Our Services

Your inquiry will be promptly replied in 12 hours

Well-trained and experienced staffs to answer your inquires in fluent English
OEM&ODM available.  any your customized lightings we can help you to design and put into product
Protection of your sales area, ideas of design and all your private information
Any defective products within warranty will get maintenance or replacement unconditionally

Quality Control
Each three workers with one QC to guarantee. Inspection Of Finish LED Light
  • Load test(Electrical spec. test) Aging test
  • High-voltage test
  • Grounding conduction test
  • Install test
  • Adhesion test
Aging test
T10 model 360 degree smd2835 g13 r17d fa8 led tube double face
Payment terms
  1. Payments: T/T & Westtern Union, Paypal.Big order 30% in advance,small all in advance
  2. MOQ:10PCS
  3. Lead time: 3-5 workdays for sample, 7-15 workdays for bulk, according to your final quantities
  4. Arrival time: 5-7 work days
  5. Warranty time: 3 years, Within the warranty period,Toplight provides free repairing service
  6. If the certain item can't be repaired,we will offer the new one for replacement at no extra cost
Company Information
Company information
T10 model 360 degree smd2835 g13 r17d fa8 led tube double face
Certification

T10 model 360 degree smd2835 g13 r17d fa8 led tube double face

FAQ



FAQ

Q:What is your main product line is made?

  • We mainly produce led application classes and industrial lighting fixtures. Including daily life indoor lighting and outdoor lighting. But led tube,led downlight,led panel light,led high bay, are our main products line.

Q:Your factory or trading company?

  • We are a factory, we provide OEM services. Some famous foreign supermarkets and we often collaborate

Q:You have the ability to do independent research and development?

  • Our engineering department has 4-5 people, we have the research and development capabilities. We also collect regularly each customer feedback, product improvement and new product development. We also hold monthly new product launches.

Q:Is there cheap shipping cost to import to our country?

  • For small order,express will be best.And for bulk order,sea ship way is best but take much time;For urgent orders,we suggest via air to airport.
