Turntable T2

Technical Information

• Motor:            8 pole, 2phase, brushless DC motor
• Driving Method:        Direct Drive
• Starting Torque:        More than 1kgf / cm
• Starting Time:        less than 1sec second
• Braking Time:        less than 1sec second
• Speed selection:        331/3 ~ 45 RPM
• Speed adjustment:    +/-10%
• Wow & Flutter:        less than 0,13% WRMS (JIS WTD)
• Tone arm type:        Static balanced S-shaped tone arm.
• Tracking Error angle:    Less than 3°
• Cartridge weight:         13~18g.
• Anti-skate range:        0~4g.
• Power supply:        230V~ 50Hz.
• Power consumption:    7 Watts
• Dimensions:        450 x 370 x 86mm (WxDxH)
• Weight:            6,5kg.
