Help CenterProfessional Audio Mixing Console/DJ Mixer SMD-2
Related Products
Specifications
Professional Audio Mixing Console/DJ Mixercertificate:CE UL
quality guarantee
best after sell service
Description:
This compact and robust battle-mixer is the perfect choice for use with two turntables (ex. XTRM-1) or tabletop CD-players (ex. DMC1000) to obtain a small but yet powerful DJ-setup with perfect sound quality!
2 channels equipped with VCA-technology and professional studio-grade dual-rail 45mm DJ-faders:
On both channels you can select internal USB-soundcard (1x bi-directional), line or phono input
Both channels have gain, 3-band EQ (+12/-26dB and full size input level meters
Extra DJ microphone input with combo (jack/XLR), 2-band EQ, level control and On-Air switch
Assignable, front-detachable, smooth 45mm hi-grade dual-rail VCA crossfader with adjustable curve.
Master section with stereo level meter and both balanced XLR + unbalanced RCA/cinch outputs
PFL section with split/blend option and PFL/main mix control
Powerful headphones output with both 6.3mm and 3.5mm stereo jacks
Record output with unbalanced RCA/cinch connectors
Technical Information
Power Supply: AC 230 V, 50Hz
Power consumption: 18W
Fuse: 20mm glass fuse 250V 1A slow
Frequency response: 20-22.000Hz (+/-3dB)
THD + noise: <0.1% @ 1kHz, 0dB
S/N Ratio (IHF-A): >80dB @ 1kHz.
Micro inputs: 1.5mV @ 10kΩ
Line/CD inputs: 150mV @ 22kΩ
Phono inputs: 3mV @ 47kΩ
Record output: 775mV @ 600Ω
Master output: 1.5V @ 4k7Ω unbal.
Master output: 850mV @ 600Ω bal.
Tone controls CH1/CH2: +12dB / -26dB @ 10kHz / 1,3kHz / 50Hz
Tone controls DJ MIC: +/-12dB @ 12kHz / 60Hz
Headphone: 180mW@75Ω
Dimensions: 240(W) x 290(H) x 104(D) mm
Weight: 2,7kg
