DJ equipment SMX-3 Professional DJ mixer,12 inputs on 6 channels
Belgium quality and design
Item name: DJ equipment, professional dj mixer
Item No: SMX-3
Brand: SYNQ
SYNQ SMX-3 series mixer for DJ Equipment has a compact control functions in all channels. Amazingly, it can gain a professional level of tone control in every functions for a high power support. Its has a beautiful design and good for Dj's aplications.
:: Product Description
* 12 inputs (2mic + 7line + 3phono) on 6 channels (5faders + 1DJ mic)
* Special matrix input selector for maximum flexibility: exchange all inputs in a second!
* 2 Master outputs:
* Master1 with signal trimming adjustment(XLR + cinchCA)
* Master2 (cinchCA)
* Gain and 3-band tone controls with kill function -30dB on all channels
* LED level meters with peak memory on all channels + Master
* User replaceable, VCA controlled, high quality faders with curve control on all channels
* User replaceable, VCA controlled, cross fader with curve control (soft  sharp
cutoff)
* Easy A/B channel selection for cross fader
* Versatile MP3-sampler:
* Based on SDHC(TM)-memory cards (several hours audio recording!)
* Max. 99 memory banks with each 5 samples on every SDHC(TM) Card!
* Stereo samples can be recorded in MP3-format (192kbps)
* Individual speed control for all samples!
* General speed control with master tempo! (pitch lock)
* Polyphony: 2 samples can be played together
* Seamless loops with editable begin and endpoints
* Sampler in/outputs assignable to any channel
* Full automatic beat counters
* Cross fader start control for compatible CD-players
* 2 Beat synchronized Cross fader mixing effects
* 8 Beat synchronized digital effects with user programmable effect presets: Echo,
Autopan, Flanger, Manual filter, Auto filter, Reverb, Trans, Pitch Shifter
* Stereo effect sendeturn to connect external effect processors.
* Adjustable DJ microphone talk-over function
* High power Phones output with "cue/pgm mixing" possibility
* Firmware upgradeable with SD(TM)/SDHC(TM)-cards.
:: Technical Information
* Input/output impedance & sensitivity (EQ flat, max. gain, level meter = 0dB)
* Line 2, 4, 6, 7 input: 340mV @ 20k Ohm (max = +4dBV)
* Line 1, 3, 5 input: 340mV @ 47k Ohm (max = +4dBV)
* Phono input: 3,4mV @ 47k Ohm (max = -36dBV)
* Mic inputs: 3,4mV @ 10k Ohm (max = -36dBV)
* Return: 525mV @ 10k Ohm
* Send: 525mV @ 2k Ohm
* Record output: 775mV @ 1k Ohm
* Masters unbalanced: 1,55V @ 100 Ohm
* Masters balanced: 2,55V @ 200 Ohm
* Headphones: 3,00V @ 33 Ohm
* Maximum output (EQ flat, max. gain, FX off, THD=1%, load is 100k Ohm )
* Master1: More than +18dBV (8,0V)
* Master2: More than +18dBV (8,0V)
* Phones: More than + 9,5dBV (3V) @ 32 Ohm
* Frequency response (EQ flat, max. gain, level meter = 0dB, load is 100k Ohm )
* Line: 25 - 20.000Hz +/-1dB
* Phono: 25 - 20.000Hz +1/-1,5dB (RIAA)
* Mic : 25 - 20.000Hz +1/-1,5dB
* THD + Noise (EQ flat, max. gain, level meter = 0dB, load is 100k Ohm )
* Line: less than 0,05% (25 - 20.000Hz)
* Phono: less than 0,05% (1kHz A-weighted)
* Mic: less than 0,1% (1kHz A-weighted)
* Channel Crosstalk (EQ flat, max. gain, Master = 0dBV)
* Crosstalk: More than 70dB @ 1kHz (between L,R & Channels)
* Tone controls:
* Mic: -12dB / +12dB @ 70Hz - 1kHz - 13kHz.
* Input channels: -30dB / +10dB @ 70Hz - 1kHz - 13kHz.
* MP3 Sampler unit:
* Sample recording: MPEG1 layer3 44,1kHz sampled @ 192kbps stereo
* Sample playback: different bitrates, editing parameters not possible
* Polyphony: 2 voices
* Memory cards: SD(TM) and SDHC(TM) cards.
* Max. card capacity: 32GB
* File format: FAT (FAT16) or FAT32 (depends on capacity)
* General specs:
* Power supply: 230V~ 50Hz. (Europe)
* Power consumption: 40Watts
* Dimensions: 320 x 370 x 109mm (WxDxH)
* Weight : 6.8kg
| Item# | SMX-3 |
| Freq. Range (all channels) | 25-20,000Hz+/-3dB |
| THD+noise (line+aux) | 0.005% (25-20,000Hz) |
| Channel Crosstalk | more than 75dB under 1kHz |
| Sampler Capacity | depends on SDHC Card |
| Dimensions (mm) | 320/W x 370/D x 109/H |
| Weight | 7 kg |
