Specifications
LED Aqua LightDMX compatible
RGB color and single color available
Quality reliable
Item Name: Summitlite LED Application Submarine Series
Item Code: SLAS1018
Product introductions:
*SLAS1018 series is for 1 watt high power version, Diameter isΦ22CM, 18PCS RGB full color (SLAS1018-AL /-SL default version), or White color SLAS1018W, Blue color SLAS1018B.
*SLAS1360 series is for low power version, Diameter is Φ22CM, the defaut RGB version with 360PCS Φ5 RGB LEDS
*SLAS1270 series 270PCS Φ5 White LEDS SLAS5270W and 270PCS Blue LEDS SLAS5270B, Green LEDs SLAS5270G , Diameter isΦ22CM,
Summitlite LED Application Submarine SLAS1XXXSeries are energy savings underwater LED lighting fixxture which utilizes high power 1W (RGB) LEDs or High Brightness dia5 LEDs as the light source to offer RGB full color and Blue color , Green color and white color as LED illumination for applications such as fountain, pond, water feature illumination, and any application with direct or indirect constant water immersion.
SLAS1XXX is a compact and state of art Aqua light with stainless steel black painted housing or Die casting aluminum housing, diameter is 22cm.
SLAS1018 operateion voltage is 24V ; the SLAS1360 RGB full color or the SLAS270-W/-G/-B is 12V version.
Summitlite LED application Submarine can be controlled in standalone mode using the SLDC1010-12V or via DMX512 using SLDC1010-12V to write the DMX Address to the fixture and it will be connected with any standard DMX-512 controller through the distribution box.
Technical Specifications:
| Item NO. | SLAS1018 | SLAS1018W | SLAS1018B | SLAS1018G |
| LED color range: | RGB, 16.7 Million | White | Blue | Green |
| Light source: | 18X1W LED(R6,G6,B6) | 18X1W Wled | 18X1W Bled | 18X1W Gled |
| Beam angle: | 25° | |||
| Data interface: | DMX compatible (RS485 connector) | |||
| DMX Channels: | 3 | |||
| Control: | DMX-512 or Simple Controller SLDC1010 | |||
| Control system | DMX Controller (or SLDC1010 DMX Address Writer) + switching power supply | |||
| synchronization controller + switching power supply | ||||
| DMX Address Set Up: | SLDC1010 DMX Address Writer | |||
| Fixture Housing: | Stainless Steel (SL) | |||
| Die Cast Aluminum (AL) | ||||
| Connector : | 3-pin power & signal connector | |||
| Voltage rated: | 24V DC | |||
| Power consumption: | 24W | |||
| IP rating | IP68 | |||
| Operating temperature: | -20°C~40°C | |||
| Submersion depth: | 0.4-2m Below Water Surface | |||
| Sustainable pressure: | 0.0533T/mm2 | |||
| Dimensions: | L255xW180xH245.4MM | |||
