Specifications
Led Tower effects lights, is a large format, outdoor, Green energy, full color changing effect, landscape enhancement product.Item Name: Summit LED Tower (outdoor)
Item no# SLAT2503
Summit LED Application products, LED Tower series consist of four types from 5m~2m, Summitlite have 25cm and 50cm two fixture diameters.
In our tiem name, SLAT(Summit LED Application Tower Series) + 25 ( means diameter 25cm)+ 02(unit meter for hight)
Summit LED Application Tower(SLAT abbrev) is a large format, outdoor, Green energy, full color changing effect, landscape enhancement product. Thorefore this is a excellent choice for square, landscape, station or even hotel with large open areas and grand biuldings
Summit LED Tower Series like the other outdoor LED application is non-direct DMX controlled fixture in order to achieve a perfect waterproof. The separated DMX controller( our item code SLDC2032 outdoor, SLDC2030 indoor) is specialized in multi-DMX function to achieve all kinds of lighting effect that incorporates with those LED Towers.
The Summit LED DMX controller with powerful function as stand-alone, linked, or DMX controller to controller functionality. The Summit LED Application Tower(SLAT) is constructed of high grade PE tubes which come in two Meter. The base tube section is mounted to a Metal base which can be anchored via bolts to a concrete pad according to your local building codes. The High Grade PE Material is Anti-UV treated and the entire Summit LED Tower is waterproof to withstand the outdoor environment.
Under standalone or standalone linked modes the Summit LED Tower produces a wide variety of preset programs from the SLDC Controllers (SLDC2030/SLDC2032) and modify the programs via the their LCD user menu. When a DMX-512 controller is connected to the SLDC you can utilize DMX to playback the pre-set programs in the SLDC and manipulate the same variables remotely via DMX that you would on the controller itself. For multiple scene capability we recommend controlling the embedded SLDC2031 (outdoor) with a standard DMX-512 controller
For more information on the functionality of the SLDC2032 /SLDC2030 and how you can use this controller as well as the DMX functionality chart refer to Summit LED DMX controller catagory.
Specifications
Item No. SLAT2502
Qty. of LEDs 1152PCS (R384, G384, B384)
Luminance 485.5Lm
Controlling Modes DMX512
Controller SLDC2032 LED DMX Controller
Input Connection 4-pin male signal connector
Output Connection 4-pin female signal connector
Input Voltage 100-240V AC
Operating Voltage 12V DC
Power Consumption Max. 135W
Operating Temperature 20°C ~ +50°C
Operating Humidity 0~95%
IP Rating IP65
Outer Tube Material Hi- Grade PE plastic
Base Aluminium
Product Size (CM) 25 x H200
General Height (CM) 221
Net Weight 30KG
Light Output
Color White Red Green Blue
Total Output (lumens) 545.1 64.5 345.6 105.3
Power (Watts) 69 15 27 27
Efficacy (lm/W) 7.9 4.3 12.8 3.9
Net Weight 260KG
Dimention(mm) 143(L)X103(W)X72(H)
Weight 0.5KG
Update Date:2010-5-13 1:31:25
