Help CenterLED Tube Light SLT38XXDMX-R
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SUMMIT
Certification:
UL, CE
Payment & Shipping
Payment Methods:
Port of Shipment:
Local Sea Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LED Tube Light SLT38XXDMX-GNegotiableMOQ: 100 Pieces -
LED Neon Flex Rope Light SLN2025RGBUS$ 1,000 - 1,200MOQ: 2 Rolls
-
LED Neon Flex Rope Light With Milky Cover SLN0025RGBUS$ 1,000 - 1,200MOQ: 2 Packs
-
LED Neon Rope Light Flex 1M ChannelUS$ 2 - 2.5MOQ: 1000 Bags
-
LED Neon Light Flex Rope Accessroy Mini ChannelUS$ 1.5 - 2MOQ: 10 Bags
Place of Origin
Guangdong, China
Brand Name
SUMMIT
Certification
UL, CE
Model Number
Other, SLT38XXDMX
Specifications
led tube light SLT38XXDMX series tube is the lastest full color energy savings LED linear Tube solution designed for pro color.Item Name: Summitlite Φ38tubes
Item NO#: SLT3803,3806,3810 series tubes
Summitlite Φ38 series was divided into three paterns and comes in 3 standard lengths which are 30, 60, and 100cm respectively based on SUMMITLITE LED technology!
Summitlite SLT38XXDMX RGB version :
SLT38XXDMX series tube is the lastest full color energy savings LED linear Tube solution designed for professional color changing projects. They can be controlled via any standard DMX-512 controller with 3, 4, and 5 channel configurations.
Summitlite SLT38XXDMX is constructed of a professional extruded aluminum profile with an optically clear polycarbonate cover and professional mounting system.
| SLT38XXDMX | ||||
| Item No | SLT3810DMX | SLT3806DMX | SLT3803DMX | |
| LED Color | RGB | |||
| Luminance | 56lm | 40Lm | 23Lm | |
| Beam Angel | 85°X40° | |||
| Tube section(mm) | Φ38 | |||
| Tube cover | Clear PC/Aluminum Base | |||
| Length | 1000mm | 600mm | 300mm | |
| LED Qty.of tube | 135PCS | 90PCS | 45PCS | |
| Operating Temperature | -20 to 40 | |||
| Operating Humidity | 0 to 95 | |||
| Protection rate | IP40 | |||
| Connector | 4-pin connector | |||
| DMX channels | 3,4,5 | |||
| Controller | Standard DMX512 controller | |||
| Functions | Color Change Color | |||
| Input Current | 1.4A | |||
| Input/output Voltage | 12V | |||
| Max Power | 12W | 8W | 4W | |
| Dimensions(MM) | 1000LX38WX70H | 670LX38WX70H | 340LX38WX70H | |
| Net Weight | 0.35KG | 0.28KG | 0.2KG | |
| Light output | ||||
| Color | Red | Green | Blue | White |
| Total output(lumen) | 22.4 | 63.0 | 15.0 | 95.2 |
| Power (Watt) | 1.9 | 3.0 | 3.0 | 6.2 |
| Efficiency(Lm/W) | 11.7 | 21.0 | 5.8 | 15.3 |
| Function | 5 Channel | 4channels | 3 channel | |
| P(dimmer) | 1ch | |||
| W | 2ch | 1ch | ||
| R | 3ch | 2ch | 1ch | |
| G | 4ch | 3ch | 2ch | |
| B | 5ch | 4ch | 3ch | |
Update Date:2010-5-13 1:50:57
