Help CenterClub 192CH Desk DMX Controller
Related Products
Specifications
12 fixture buttons 16 channels each 30 banks 8 programmable scenes 6 chases 240 8 sliders Built in microphone Non-Volatile FogSummitlite Entertainment Controller Series Introduction:
Summitlite Entertainment Controller DMX 512 Series are a popular and standard DMX 512 controller system. Compatible to international universal DMX512 signal protocal(USITT , ESTA)
Summitlite International Support a wide range of standard DMX controller in most of small or professional Stage and DJ venue.
Meanwhile, Summitlite put the Power pack(SEC1XXX) and Dimmer pack(SEC20XX), Dimmer controller(SEC22XX&SEC23XX), Chase controller(SEC24XX&SEC25XX), and Strobe Controller(SEC26XX) even DMX distributor packSEC(60XX) under this family to make Summitelite as a integrated solution for stage builder and designer or our distributors.
All above items are mainly support our client on OEM solution with a reliable service and stability of quality.
Summitlite Entertainment Controller Including Below series:
1.SEC5XXX Series: Professional DMX controller
Sunmmitlite Entertainment Controller(Abbre. SEC) below 512DMX CH
"5XXX" is for profesional utility in stage and Club application.
"XXX" is the numbers of DMX channel under this series. Now we use 512CH, 192CH, and 144CH etc. for this range.
The letter "a, or b, c..." suffix means different patterns
Ex. SEC5512b will means Summit Entertainment Controller professional 512CH DMX Conterller pattern "b"
The pattern" b" is means a change of both housing, etc outlook or fuctional redesign based on different application.
2. SEC3XXX Series: General DMX controller below 100CH
Sunmmitlite Entertainment Controller(Abbre. SEC)
"30XX" is for universal utility in stage and Club application.
"XX" is the numbers of DMX channel under this series. Now we use 48CH, 36CH,32CH,24CH, 16CH, etc.
The letter "a, or b, c..." suffix means different patterns
Ex. SEC3016c will means Summit Entertainment Controller stage 16CH DMX Conterller pattern "c", for the feature and function, please follow our catagory to get more details.
The Summitlite DMX controller is all round use and programable DMX console. Hi-quality slader, lianear dimmer 0~100% or DMX value 0~255, LED Display LED interference. We the the profesional version SEC5XXX sereies and stage standard series SEC3XXX sreise. All Channel Fixture Buttons and similar information in similar types of controllers.
SEC5192c Product Features:
* 12 fixture buttons with 16 channels each
* 30 banks of 8 programmable scenes
* 6 programmable chases of 240 scenes each
* 8 sliders for manual control of channels
* 2 assignable fine adjustment wheels for ease of movement
* 8 Bit or 16 Bit mode
* Manual override button allow you to grab any fixture on the fly
* Built in microphone
* Midi Trigger
* Non-Volatile Memory
* Fog machine connector
Technical Specification:
| Item Name | DMX Controller |
| Item Code | SEC5192c |
| DMX output channels | 192 |
| Power input | DC 9-12V 300ma min |
| Audio input | by built-in microphone or line in, 100mv-1vpp |
| Midi | 5-pin DIN |
| DMX output | 2 (1 3-pin XLR female, 1 3-pin XLR male) |
| Voltage | AC 120/240V 50/60Hz |
| Housing | Racked Rails |
| Dimensions | L516 x W160 x H90mm |
| Weight | 2.7 kg |
