Help CenterDMX Controller Stage Desk 48CH SEC3048b
Related Products
-
DMX Controller SEC5512bUS$ 1 - 20MOQ: 50 Pieces -
DMX Controller Stage Racked 48CH SEC3048aNegotiableMOQ: 50 Pieces
-
DMX Controller SEC5512aUS$ 1 - 100MOQ: 50 Pieces
-
DMX Controller Stage Racked 36CH SEC3036aNegotiableMOQ: 50 Pieces
-
DMX Controller Stage Desk 24CH SEC3024bNegotiableMOQ: 50 Pieces
Specifications
DMX Controller Stage Racked SEC3048b48 DMX control channels
96 chaser programs
Plastic rails designed on Desk.
tem Name:Stage Desk 48CH DMX Controller
Item Code:SEC3048b
Keywords: Stage 48CH DMX controller
Summitlite Entertainment Controller Series Introduction:
Summitlite Entertainment Controller DMX 512 Series are a popular and standard DMX 512 controller system. Compatible to international universal DMX512 signal protocal(USITT , ESTA)
Summitlite International Support a wide range of standard DMX controller in most of small or professional Stage and DJ venue.
Meanwhile, Summitlite put the Power pack(SEC1XXX) and Dimmer pack(SEC20XX), Dimmer controller(SEC22XX&SEC23XX), Chase controller(SEC24XX&SEC25XX), and Strobe Controller(SEC26XX) even DMX distributor packSEC(60XX) under this family to make Summitelite as a integrated solution for stage builder and designer or our distributors.
All above items are mainly support our client on OEM solution with a reliable service and stability of quality.
Summitlite Entertainment Controller Including Below series:
1.SEC5XXX Series: Professional DMX controller
Sunmmitlite Entertainment Controller(Abbre. SEC) below 512DMX CH
"5XXX" is for profesional utility in stage and Club application.
"XXX" is the numbers of DMX channel under this series. Now we use 512CH, 192CH, and 144CH etc. for this range.
The letter "a, or b, c..." suffix means different patterns
Ex. SEC5512b will means Summit Entertainment Controller professional 512CH DMX Conterller pattern "b"
The pattern" b" is means a change of both housing, etc outlook or fuctional redesign based on different application.
2. SEC3XXX Series: General DMX controller below 100CH
Sunmmitlite Entertainment Controller(Abbre. SEC)
"30XX" is for universal utility in stage and Club application.
"XX" is the numbers of DMX channel under this series. Now we use 48CH, 36CH,32CH,24CH, 16CH, etc.
The letter "a, or b, c..." suffix means different patterns
Ex. SEC3016c will means Summit Entertainment Controller stage 16CH DMX Conterller pattern "c", for the feature and function, please follow our catagory to get more details.
The Summitlite DMX controller is full function and programable DMX console. Hi-quality slader, lianear dimmer 0~100% or DMX value 0~255, LED Display LED interference. We the the profesional version SEC5XXX sereies and stage standard series SEC3XXX sreise. All Channel Fixture Buttons and similar information in similar types of controllers.
SEC3048b is functionally same with SEC3048a , but it is design for Desk with plastic rails.
Product Features:
* 48 DMX control channels
* 96 chaser programs
* 2 Independent dipless crossfaders
* 3 Digit LCD diplay
* Digital technology adopted
* Power failure memory
* Standard MIDI and DMX ports
* Powerful program edit
* Various running type
* More programs can run synchronously
Product specifications:
| Item Name | Stage Desk 48CH DMX Controller |
| Item Code | SEC3048b |
| DMX Channel | 48 |
| chaser programs | 96 |
| Midi | 5-pin DIN |
| Audio input | by built-in microphone or line in 100mv-1 vpp |
| Power supply | DC 12-20V 500MA min |
| DMX output | 2 (1 3-pin XLR female, 1 3-pin XLR male) |
| Voltage | AC 120/240V 50/60Hz |
| Housing | Plastic Controller Rails |
| Dimensions | L744 x W294 x H90mm |
| Weight | 7.5 kg |
