50% Power Saving Welding Machines, 5L Oil Tank Engine & Outdoor MMA Welders, Current Digital Control Feedback
Features:
A> Welding Performance
Adopting digital control feedback technology to control current.
The current is smooth, good dynamic characteristic.
Fast response and ARC length fluctuation is small.
Easy to start ARC, little spatter, stable current and good formation.
Welding current as the digital display, can adjust the current.
Accurately adjustment. Good for welding process specification.
100% high duty cycle.
Strong ARC froce, soft arc.
B> Generation performance
Adopt digital control technology to make small waveform distortion and low distortion rate.
High efficiency.20% higher power than the same generator.
Protection for over load & over hot.
C> Machine Performance
High reliability and practicality.
Using all-in-one structural design.
Simple and reliable structure.Durable & easy maintenance.
Widely used in city, outdoors, high & low temperature environment.
Welder |
Welding type |
MMA |
No-load voltage (V) |
68 |
|
Rated current (A) |
90 |
|
Maximum current (A) |
120 |
|
Current range (A) |
30 - 120 |
|
Duty cycle Imax |
60% |
|
Electrode diameter (mm) |
1.6 – 3.2 |
|
Engine |
Maximum power (KW) |
3.2 |
Rated power (KW) |
2.8 |
|
Rated voltage (V) |
AC220 |
|
Frequency (Hz) |
50 |
|
Phases |
Single phase |
|
Power ()hp |
6.5 |
|
Air displacement (ml) |
200 |
|
Valve type |
Overhead |
|
Fire method |
CDI |
|
Oil tank capacity (l) |
5 |
|
Oil waring system |
Exist |
|
Speed (r/ min) |
3600 |
|
Fuel consumption (g/hp.hr) |
230 |
|
Starting up |
Manual starting |
|
Complete appliance |
Insulation class |
IP23 |
Dimension (mm) |
550 * 490 * 460 |
|
Weight (kg) |
45 |
Products Showcase:
| Package: | 1 set into 1 export carton |
| Express delivery: | 4-5 days |
| Air freight: | 3-4 days |
| Sea delivery: | 30-35 days |
| samples order: | 2-3 days |
| massive order: | 25-30 days |
Established in 2010, Shenzhen Unitweld Welding & Motor Co.,Ltd. is the earliest professional manufacturer of welding machines, torches, and welding accessories.
After 5 years of persistent pursuit and unremitting efforts, we have become the leading factory in domestic and international markets.
1.Q: Are you factory or trading company?
A: We are factory,we mainly produce inverter welding machines and plasma cutting machines.
2.Q: Where is your factory located?How can i visit there?
A: Our factory is located in Shenzhen city,Guangdong province.
Also we attend many fair and exhibitions, including on oversea soil.
Welcome to leave us your contact information, we can pay you a visit right at your office.
3.Q: What Certificate do you have?
A: We have CE,CCC,RoHs.
Also welcome to tell us what certification you need in your country specially.
4.Q: How many days it take for mass production?
A: Usually it takes 25-30 workdays after confirming order.
5.Q: What payment terms you support?
A: We accept T/T, Paypal, Western Union, and L/C.
6.Q: Can you do OEM services?
A: Yes, we do OEM/ODM services.
7.Q: Will you provide spare parts?
A: We shall offer spare parts according to your order details.
8.Q: What is your guarantee period?
A: We offer 1 year quality guarantee.
